3
8717B–SEEPR–6/10
Atmel AT24C32D/64D
2. Pin Description
SERIAL CLOCK (SCL): The SCL input is used to positive edge clock data into each EEPROM device and
negative edge clock data out of each device.
SERIAL DATA (SDA): The SDA pin is bidirectional for serial data transfer. This pin is open-drain driven and may
be wire-ORed with any number of other open-drain or open collector devices.
DEVICE/ADDRESSES (A2, A1, A0): The A2, A1 and A0 pins are device address inputs that are hard wired or left
not connected for hardware compatibility with other Atmel
®
AT24CXX devices. When the pins are hardwired, as
many as eight 32K/64K devices may be addressed on a single bus system (device addressing is discussed in
detail under the Device Addressing section). If the pins are left floating, the A2, A1 and A0 pins will be internally
pulled down to GND if the capacitive coupling to the circuit board V
CC
plane is <3pF. If coupling is >3pF, Atmel
recommends connecting the address pins to GND.
WRITE PROTECT (WP): The write protect input, when connected to GND, allows normal write operations. When
WP is connected high to V
CC
, all write operations to the memory are inhibited. If the pin is left floating, the WP pin
will be internally pulled down to GND if the capacitive coupling to the circuit board V
CC
plane is <3pF. If coupling is
>3pF, Atmel recommends connecting the pin to GND.
