Atmel AT24C32D/64D
Table 3-3. AC Characteristics
Notes: 1. This parameter is ensured by characterization
2. AC measurement conditions:
R
L
(connects to V
CC
): 1.3k (2.5V, 5.0V), 10k (1.7V)
Input pulse voltages: 0.3 V
CC
to 0.7 V
CC
Input rise and fall times: 50ns
Input and output timing reference voltages: 0.5 V
CC
Applicable over recommended operating range from T
AI
= -40Cto+85C, V
CC
= +1.7V to +5.5V, CL = 1 TTL Gate and
100pF (unless otherwise noted)
Symbol Parameter
1.7V 5.0V
Min Max Min Max Units
f
SCL
Clock Frequency, SCL 400 1000 kHz
t
LOW
Clock Pulse Width Low 1.3 0.4 µs
t
HIGH
Clock Pulse Width High 0.6 0.4 µs
t
i
Noise Suppression Time
(1)
100 50 ns
t
AA
Clock Low to Data Out Valid 0.05 0.9 0.05 0.55 µs
t
BUF
Time the bus must be free before a new
transmission can start
(1)
1.3 0.5 µs
t
HD.STA
Start Hold Time 0.6 0.25 µs
t
SU.STA
Start Set-up Time 0.6 0.25 µs
t
HD.DAT
Data In Hold Time 0 0 µs
t
SU.DAT
Data In Set-up Time 100 100 ns
t
R
Inputs Rise Time
(1)
0.3 0.3 µs
t
F
Inputs Fall Time
(1)
300 100 ns
t
SU.STO
Stop Set-up Time 0.6 0.25 µs
t
DH
Data Out Hold Time 50 50 ns
t
WR
Write Cycle Time 5 5 ms
Endurance
(1)
25°C, Page Mode, 3.3V 1,000,000 Write Cycles
