5
6384E–ATARM–05-Feb-10
AT91SAM9G20
3. Signal Description
Table 3-1. Signal Description List (Continued)
Signal Name Function Type
Active
Level Comments
Power Supplies
VDDIOM EBI I/O Lines Power Supply Power 1.65V to 1.95V or 3.0V to 3.6V
VDDIOP Peripherals I/O Lines Power Supply Power 1.65V to 3.6V
VDDBU Backup I/O Lines Power Supply Power 0.9V to 1.1V
VDDANA Analog Power Supply Power 3.0V to 3.6V
VDDPLL PLL Power Supply Power 0.9V to 1.1V
VDDOSC Oscillator Power Supply Power 1.65V to 3.6V
VDDCORE Core Chip Power Supply Power 0.9V to 1.1V
VDDUSB USB Power Supply Power 1.65V to 3.6V
GND Ground Ground
GNDANA Analog Ground Ground
GNDBU Backup Ground Ground
GNDUSB USB Ground Ground
GNDPLL PLL Ground Ground
Clocks, Oscillators and PLLs
XIN Main Oscillator Input Input
XOUT Main Oscillator Output Output
XIN32 Slow Clock Oscillator Input Input
XOUT32 Slow Clock Oscillator Output Output
OSCSEL Slow Clock Oscillator Selection Input
Accepts between 0V and
VDDBU.
PCK0 - PCK1 Programmable Clock Output Output
Shutdown, Wakeup Logic
SHDN Shutdown Control Output
WKUP Wake-up Input Input
Accepts between 0V and
VDDBU.
ICE and JTAG
NTRST Test Reset Signal Input Low Pull-up resistor
TCK Test Clock Input No pull-up resistor
TDI Test Data In Input No pull-up resistor
TDO Test Data Out Output
TMS Test Mode Select Input No pull-up resistor
JTAGSEL JTAG Selection Input
Pull-down resistor. Accepts
between 0V and VDDBU.
RTCK Return Test Clock Output
