SAM9G20
DS60001516A-page 6 2017 Microchip Technology Inc.
Reset/Test
NRST Microprocessor Reset I/O Low Pull-up resistor
TST Test Mode Select Input –
Pull-down resistor. Accepts
between 0V and VDDBU.
BMS Boot Mode Select Input –
No pull-up resistor
BMS = 0 when tied to GND
BMS = 1 when tied to VDDIOP
Debug Unit - DBGU
DRXD Debug Receive Data Input –
DTXD Debug Transmit Data Output –
Advanced Interrupt Controller - AIC
IRQ0–IRQ2 External Interrupt Inputs Input –
FIQ Fast Interrupt Input Input –
PIO Controller - PIOA / PIOB / PIOC
PA0–PA31 Parallel IO Controller A I/O – Pulled-up input at reset
PB0–PB31 Parallel IO Controller B I/O – Pulled-up input at reset
PC0–PC31 Parallel IO Controller C I/O – Pulled-up input at reset
External Bus Interface - EBI
D0–D31 Data Bus I/O – Pulled-up input at reset
A0–A25 Address Bus Output – 0 at reset
NWAIT External Wait Signal Input Low
Static Memory Controller - SMC
NCS0–NCS7 Chip Select Lines Output Low
NWR0–NWR3 Write Signal Output Low
NRD Read Signal Output Low
NWE Write Enable Output Low
NBS0–NBS3 Byte Mask Signal Output Low
CompactFlash Support
CFCE1–CFCE2 CompactFlash Chip Enable Output Low
CFOE CompactFlash Output Enable Output Low
CFWE CompactFlash Write Enable Output Low
CFIOR CompactFlash IO Read Output Low
CFIOW CompactFlash IO Write Output Low
CFRNW CompactFlash Read Not Write Output –
CFCS0–CFCS1 CompactFlash Chip Select Lines Output Low
Table 2-1: Signal Description List
Signal Name Function Type Active Level Comments
