SAM9G25 [DATASHEET]
Atmel-11032F-ATARM-SAMG25-Datasheet_10-Mar-15
2
1. Features
Core
ARM926EJ-S™ ARM
®
Thumb
®
Processor running at up to 400 MHz @ 1.0V +/- 10%
16 Kbytes Data Cache, 16 Kbytes Instruction Cache, Memory Management Unit
Memories
One 64-Kbyte internal ROM embedding bootstrap routine: Boot on NAND Flash, SDCard, DataFlash
®
or
serial DataFlash. Programmable order.
One 32-Kbyte internal SRAM, single-cycle access at system speed
High Bandwidth Multi-port DDR2 Controller
32-bit External Bus Interface supporting 4-bank and 8-bank DDR2/LPDDR, SDR/LPSDR, Static Memories
MLC/SLC 8-bit NAND Controller, with up to 24-bit Programmable Multibit Error Correcting Code (PMECC)
System running at up to 133 MHz
Power-on Reset Cells, Reset Controller, Shut Down Controller, Periodic Interval Timer, Watchdog Timer
and Real Time Clock
Boot Mode Select Option, Remap Command
Internal Low Power 32 kHz RC and Fast 12 MHz RC Oscillators
Selectable 32768 Hz Low-power Oscillator and 12 MHz Oscillator
One PLL for the system and one PLL at 480 MHz optimized for USB High Speed
Twelve 32-bit-layer AHB Bus Matrix for large Bandwidth transfers
Dual Peripheral Bridge with dedicated programmable clock for best performance
Two dual port 8-channel DMA Controllers
Advanced Interrupt Controller and Debug Unit
Two Programmable External Clock Signals
Low Power Mode
Shut Down Controller with four 32-bit Battery Backup Registers
Clock Generator and Power Management Controller
Very Slow Clock Operating Mode, Software Programmable Power Optimization Capabilities
Peripherals
ITU-R BT. 601/656 Image Sensor Interface
USB Device High Speed, USB Host High Speed and USB Host Full Speed with dedicated On-Chip
Transceiver
One 10/100 Mbps Ethernet MAC Controller
Two High Speed Memory Card Hosts
Two Master/Slave Serial Peripheral Interface
Two 3-channel 32-bit Timer/Counters
One Synchronous Serial Controller
One 4-channel 16-bit PWM Controller
Three Two-wire Interfaces
Four USARTs, two UARTs, one DBGU
One 12-channel 10-bit Analog-to-Digital Converter
Soft Modem
Write Protected Registers
I/O
Four 32-bit Parallel Input/Output Controllers
105 Programmable I/O Lines Multiplexed with up to Three Peripheral I/Os
Input Change Interrupt Capability on Each I/O Line, optional Schmitt trigger input
