Datasheet 搜索 > 32位控制器 > ATMEL（爱特美尔） > AT91SAM9G45C-CU 数据手册 > AT91SAM9G45C-CU 产品封装文件 1/1240 页
器件3D模型￥ 50.338
AT91SAM9G45C-CU 产品封装文件 - ATMEL（爱特美尔）
制造商:
ATMEL（爱特美尔）
分类:
32位控制器
封装:
TFBGA-324
描述:
ATMEL AT91SAM9G45C-CU 微控制器, 32位, ARM Thumb, ARM9, 400 MHz, 64 KB, 64 KB, 324 引脚, TFBGA
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
引脚图在P53P367P423P494P657P709P710P770P942P1060P1062Hot
典型应用电路图在P52P496P511P599P671P832P836
原理图在P3P21P33P51P70P84P92P109P116P123P157P162
封装尺寸在P1202P1203P1223P1226
型号编码规则在P1205P1221P1224
标记信息在P1204P1224
封装信息在P1203
功能描述在P54P71P84P93P110P117P124P167P232P271P315P368
应用领域在P366P1239
电气规格在P71P364P943P944P1172P1174P1176P1202P1223P1224P1225P1226
导航目录
AT91SAM9G45C-CU数据手册
Page:
of 1240 Go
若手册格式错乱，请下载阅览PDF原文件
Atmel-6438L-ATARM-SAM9G45-Datasheet_19-Aug-14
Description
The Atmel
®
| SMART ARM926EJ-S™-based SAM9G45 features the frequently
demanded combination of user interface functionality and high data rate
connectivity, including LCD Controller, resistive touch-screen, camera interface,
audio, Ethernet 10/100 and high speed USB and SDIO. With the processor
running at 400 MHz and multiple 100+ Mbps data rate peripherals, the SAM9G45
has the performance and bandwidth to the network or local storage media to
provide an adequate user experience.
The SAM9G45 supports DDR2 and NAND Flash memory interfaces for program
and data storage. An internal 133 MHz multi-layer bus architecture associated
with 37 DMA channels, a dual external bus interface and distributed memory
including a 64-Kbyte SRAM which can be configured as a tightly coupled memory
(TCM) sustains the high bandwidth required by the processor and the high speed
peripherals.
The I/Os support 1.8V or 3.3V operation, which are independently configurable for
the memory interface and peripheral I/Os. This feature completely eliminates the
need for any external level shifters. In addition it supports 0.8 ball pitch package
for low cost PCB manufacturing.
The SAM9G45 power management controller features efficient clock gating and a
battery backup section minimizing power consumption in active and standby
modes.
SAM9G45
Atmel | SMART ARM-based Embedded MPU
DATASHEET
