Atmel-6355I-ATARM-SAM9M10-Datasheet_17-Dec-15
Description
The Atmel
®
| SMART SAM9M10 is a multimedia-enabled mid-range ARM926-
based embedded MPU running at 400 MHz, combining user interfaces, video
playback and connectivity. It includes hardware video decoder, LCD Controller,
resistive touchscreen, camera interface, audio, Ethernet 10/100 and high speed
USB and SDIO.
The hardware video decoder supports the standards H.264, MPEG-4, MPEG-2,
VC-1, and H.263. The SAM9M10 also provides hardware image post-processing,
such as image scaling, color conversion and image rotation.
The SAM9M10 supports DDR2 and NAND Flash memory interfaces for program
and data storage. An internal 133 MHz multi-layer bus architecture associated
with 37 DMA channels, a dual external bus interface and distributed memory
including a 64-Kbyte SRAM which can be configured as a tightly coupled memory
(TCM) sustains the high bandwidth required by the processor and the high speed
peripherals.
A True Random Number Generator is embedded for key generation and
exchange protocols.
The I/Os support 1.8V or 3.3V operation, which are independently configurable for
the memory interface and peripheral I/Os. This feature completely eliminates the
need for any external level shifters. In addition it supports a 0.8 mm ball pitch
package for low cost PCB manufacturing.
The SAM9M10 devices have three software-selectable low-power modes: Idle,
Ultra Low-power and Backup. In Idle mode, the processor is stopped while all
other functions can be kept running at normal operating bus frequency. In Ultra
Low-power mode, the processor is stopped while all other functions can be kept
running at minimum operating bus frequency. In Backup mode, only the real-time
clock, real-time timer, 128-bit general purpose backup registers, and wake-up
logic are running.
The SAM9M10 power management controller features efficient clock gating and a
battery backup section minimizing power consumption in active and standby
modes.
The SAM9M10 device is particularly well suited for media-rich displays and
control panels in home and commercial buildings, POS terminals, entertainment
systems, internet appliances and medical.
SAM9M10
Atmel | SMART ARM-based Embedded MPU
DATASHEET
