Description
The Atmel
®
| SMART SAM9M10 is a multimedia-enabled mid-range ARM926-
based embedded MPU running at 400MHz, combining user interfaces, video
playback and connectivity. It includes hardware video decoder, LCD Controller,
resistive touchscreen, camera interface, audio, Ethernet 10/100 and high speed
USB and SDIO.
The hardware video decoder supports H.264, MPEG-4, MPEG-2, VC-1, H.263.
The SAM9M10 also provides hardware image post-processing, such as image
scaling, color conversion and image rotation.
The SAM9M10 supports the latest generation of DDR2 and NAND Flash memory
interfaces for program and data storage. An internal 133 MHz multi-layer bus
architecture associated with 37 DMA channels, a dual external bus interface and
distributed memory including a 64-KByte SRAM which can be configured as a
tightly coupled memory (TCM) sustains the high bandwidth required by the
processor and the high speed peripherals.
The I/Os support 1.8V or 3.3V operation, which are independently configurable for
the memory interface and peripheral I/Os. This feature completely eliminates the
need for any external level shifters. In addition it supports 0.8 ball pitch package
for low cost PCB manufacturing.
The SAM9M10 power management controller features efficient clock gating and a
battery backup section minimizing power consumption in active and standby
modes.
The SAM9M10 device is particularly well suited for media-rich displays and
control panels in home and commercial buildings, POS terminals, entertainment
systems, internet appliances and medical.
SAM9M10
Atmel | SMART ARM-based Embedded MPU
DATASHEET
