AT93C46D-TH-B数据手册
Page:
of 21 Go
若手册格式错乱，请下载阅览PDF原文件
Atmel-5193G-SEEPROM-AT93C46D-Datasheet_082014
Features
Low-voltage Operation
V
CC
= 1.8V to 5.5V
User-selectable Internal Organization
1K: 128 x 8 or 64 x 16
3-wire Serial Interface
2MHz Clock Rate (5V)
Self-timed Write Cycle (5ms Max)
High Reliability
Endurance: 1,000,000 Write Cycles
Data Retention: 100 Years
8-lead JEDEC SOIC, 8-lead TSSOP, 8-pad UDFN, 8-lead PDIP, and
8-ball VFBGA Packages
Description
The Atmel
®
AT93C46D provides 1,024 bits of Serial Electrically Erasable
Programmable Read-Only Memory (EEPROM) organized as 64 words of 16 bits
each (when the ORG pin is connected to V
CC
) and 128 words of 8 bits each (when
the ORG pin is tied to ground). The device is optimized for use in many industrial
and commercial applications where low-power and low-voltage operations are
essential. The AT93C46D is available in space-saving 8-lead JEDEC SOIC,
8-lead TSSOP, 8-pad UDFN, 8-lead PDIP, and 8-ball VFBGA packages.
The AT93C46D is enabled through the Chip Select pin (CS) and accessed via a
3-wire serial interface consisting of Data Input (DI), Data Output (DO), and Shift
Clock (SK). Upon receiving a Read instruction at DI, the address is decoded, and
the data is clocked out serially on the DO pin. The write cycle is completely
self-timed, and no separate erase cycle is required before Write. The write cycle is
only enabled when the part is in the Erase/Write Enable state. When CS is
brought high following the initiation of a write cycle, the DO pin outputs the
Ready/Busy status of the part.
The AT93C46D operates from 1.8V to 5.5V.
AT93C46D
3-wire Serial EEPROM
1K (128 x 8 or 64 x 16)
DATASHEET
