• Batronix Elektronik • Torweg 18 • 24211 Lehmkuhlen •
• www.Batronix.com • Service@Batronix.com • Germany •
PROFESSIONAL PROGRAMMER SERIES
The new Batronix Professional Programmer Series offers an
exceptionally flexible, simple to use and extremely fast set of
programming devices that support a broad range of chips including
Eproms, EEproms, Flash, serial EEproms and other storage chips.
With a height of only 2.5 cm the enclosures are very practical and are
noted for their design and anodized die-cast aluminum construction.
These programming devices are your first choice even in a harsh
usage environment.
The exceptional flexibility is attained by providing all power requirements via the USB
port. A power adapter or batteries are not required, since all programming voltages
between 3 and 25 volts are provided internally by a voltage generator from the USB
supply voltage. The chips are programmed at a high level of quality and reproducibility in
the shortest time possible through the use of optimized algorithms and micro-controller
managed programming times. All supported chips can be programmed directly in DIP/DIL
packages and suitable adapters are available for specialized packages such as PLCC,
SOP, TSOP and QFP.
Chip Support
BX32
Batupo
BX32P
Barlino
BX40
Bagero
27’ NMOS from 2732
27C, 27E, 27SF, 28, 28C, 28F, 28HC,
28SF, 29C, 48’ , 87’, ...
29F (BX32/BX32P: without
29F100/200/400/800)
29LV, 29W, ...
39’, 49’, LPC, FWH
24’, 25’, 93’, 95’ serial EEproms
29F100/200/400/800
16 Bit Chips
Free device add on customer request
Special Hardware Features
BX32, BX32P and BX40
USB Powered (no power adapter required)
Chip Auto Identification (identifies chips automatically)
Multi Programmer Control (up to 8 programmer at one PC)
Automatic Programming Start (for mass production)
High Speed Technology
