ATmega3209/4809 – 48-pin
Data Sheet
megaAVR® 0-series
Introduction
The ATmega3208/3209/4808/4809 microcontrollers of the megaAVR
®
0-series are using the AVR
®
processor with hardware multiplier, running at up to 20 MHz, with a wide range of Flash sizes up to 48
KB, up to 6 KB of SRAM, and 256 bytes of EEPROM in 28-, 32-, or 48-pin package. The series uses the
latest technologies from Microchip with a flexible and low-power architecture including Event System and
SleepWalking, accurate analog features and advanced peripherals.
The devices described here offer Flash sizes from 32 KB to 48 KB in a 48-pin package.
Features
• AVR
®
CPU
– Single-cycle I/O access
– Two-level interrupt controller
– Two-cycle hardware multiplier
• Memories
– Up to 48 KB In-system self-programmable Flash memory
– 256B EEPROM
– Up to 6 KB SRAM
– Write/Erase endurance:
• Flash 10,000 cycles
• EEPROM 100,000 cycles
– Data retention: 20 Years at 85°C
• System
– Power-on Reset (POR) circuit
– Brown-out Detection (BOD)
– Clock options:
• 20 MHz low power internal oscillator with fuse-protected frequency setting
• 32.768 kHz Ultra Low Power (ULP) internal oscillator
• 32.768 kHz external crystal oscillator
• External clock input
– Single pin Unified Program Debug Interface (UPDI)
– Three sleep modes:
• Idle with all peripherals running and mode for immediate wake-up time
• Standby
– Configurable operation of selected peripherals
© 2018 Microchip Technology Inc.
Datasheet Preliminary
DS40002016A-page 1
