Lead-free
BAS40DW-05
Marking: K45
BAS40TW
Marking: K43
BAS40DW-04
Marking: K44
DS30156 Rev. 10 - 2 1 of 3 BAS40TW /DW-04 /DW-05 /DW-06 /BRW
www.diodes.com
ã Diodes Incorporated
BAS40TW /DW-04 /DW-05 /
DW-06 /BRW
SURFACE MOUNT SCHOTTKY BARRIER DIODE ARRAYS
Features
Mechanical Data
·
Low Forward Voltage Drop
·
Fast Switching
·
Ultra-Small Surface Mount Package
·
PN Junction Guard Ring for Transient and
ESD Protection
·
Lead Free/RoHS Compliant (Note 3)
·
Qualified to AEC-Q101 Standards for High Reliability
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
40 V
RMS Reverse Voltage
V
R(RMS)
28 V
Forward Continuous Current (Note 1)
I
FM
200 mA
Non-Repetitive Peak Forward Surge Current @ t < 1.0s
I
FSM
600 mA
Power Dissipation (Note 1)
P
d
200 mW
Thermal Resistance Junction to Ambient Air (Note 1)
R
qJA
625 °C/W
Operating and Storage Temperature Range
T
j
,
T
STG
-55 to +125
-65 to +125
°C
Notes: 1. Part mounted on FR-4 board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
2. Short duration test pulse used to minimize self-heating effect.
3. No purposefully added lead.
A
M
J
L
D
B
C
H
K
G
F
Characteristic Symbol Min Max Unit Test Condition
Reverse Breakdown Voltage (Note 2)
V
(BR)R
40
¾
V
I
R
= 10mA
Forward Voltage
V
F
¾
380
1000
mV
mV
I
F
= 1.0mA, t
p
< 300ms
I
F
= 40mA, t
p
< 300ms
Reverse Current (Note 2)
I
R
¾ 200 nA
V
R
= 30V
Total Capacitance
C
T
¾ 5.0 pF
V
R
= 0, f = 1.0MHz
Reverse Recovery Time
t
rr
¾ 5.0 ns
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
,R
L
= 100W
Electrical Characteristics
@ T
A
= 25°C unless otherwise specified
A
1
A
2
C
2
C
1
C
2
C
1
BAS40DW-06
Marking: K46
C
1
C
2
A
2
A
1
A
2
A
1
AC
1
AC
2
C
2
A
1
A
2
C
1
AC
1
AC
2
C
1
A
1
C
2
A
2
C
1
A
3
C
2
A
1
C
3
A
2
SOT-363
Dim Min Max
A
0.10 0.30
B
1.15 1.35
C
2.00 2.20
D
0.65 Nominal
F
0.30 0.40
H
1.80 2.20
J
¾ 0.10
K
0.90 1.00
L
0.25 0.40
M
0.10 0.25
a
0° 8°
All Dimensions in mm
@ T
A
= 25°C unless otherwise specified
TOP VIEW
·
Case: SOT-363
·
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
·
Moisture Sensitivity: Level 1 per J-STD-020C
·
Terminals: Solderable per MIL-STD-202, Method 208
·
Lead Free Plating (Matte Tin Finish annealed
over Alloy 42 leadframe).
·
Polarity: See Diagrams Below
·
Marking: See Diagrams Below & Page 3
·
Weight: 0.006 grams (approximate)
BAS40BRW
Marking: K47
Maximum Ratings
SPICE MODELS: BAS40TW BAS40DW-04 BAS40DW-05 BAS40DW-06 BAS40BRW
