Find out more about TI Low-Power RF
http://www.ti.com/lprf
Low-Power RF ICs from
Texas Instruments
Peer to Peer / Star networks
Proprietary
In some cases, it may be desirable to develop your own
networking protocol. To help you do this, TI provides a
MSP430-CC library, so that you can easily interface the
MSP430 to one of the CCxx0x devices.
Who is it suitable for?
This is suitable for undergraduate or postgraduate
projects with specific wireless requirements which cannot
be met by the simpliciTI or Z-Accel.
Compatible Hardware:
- CCxx0x EMK + MSP430 Experimenters board*.
- eZ430-RF2500
Software Required:
IAR Embedded Workbench for MSP430
(can be modified to work with CCE)
For more information, see document: SWRA141
Simplici TI
SimpliciTI is a simple low-power RF network protocol
aimed at small RF networks. Access point and range
extenders are not required, but provide extra functionality
such as store and forward messages.
Who is it suitable for?
Undergraduate projects, to develop simple peer-to-peer
or star networks with only one hop.
Compatible Hardware:
- CCxx0x EMK + MSP430 Experimenters board*
- eZ430-RF2500
Software Required:
IAR Embedded Workbench for MSP430
For more information:
http://focus.ti.com/docs/toolsw/folders/print/simpliciti.html
TI MAC
The Medium Access Control stack offers full 802.15.4
compatibility. It also offers easy migration to ZigBee if
required.
Who is it suitable for?
Post graduates or professors, who want to develop and
analyze complex peer-to-peer or star networks with only
one hop. It is suited for low data rate applications.
Compatible Hardware:
- CC243x DK
- CC2520 DK / ZDK
Software Required:
IAR embedded workbench
For more information: www.ti.com/timac
All protocols and software, except IAR Embedded
Workbench, are free to download.
* The MSP430 Experimenters Board also required a
programmer to be able to program the MSP430.
Suitable programmers are:
MSP-FET430UIF
http://focus.ti.com/docs/toolsw/folders/print/msp-fet430uif.html
MSP-FET430PIF
http://focus.ti.com/docs/toolsw/folders/print/msp-fet430pif.html
Mesh Networks
Z-Accel
Z-Accel is a solution where TI’s Z-Stack, runs on a
ZigBee Processor and the application runs on an
external microcontroller.
Who is it suitable for?
Undergraduate projects, to develop simple mesh
networks with more than one hop and to develop ZigBee
compliant networks.
Compatible Hardware:
- eZ430-RF2480
Software Required:
IAR Embedded Workbench
For more information, see document: SWRA176
Z-Stack
Z-Stack is compliant with both the ZigBee 2007 (ZigBee
PRO) and ZigBee® 2006 specification. Z-Stack™
supports ZigBee on the CC243x SoC and supports both
ZigBee and ZigBee PRO when combining an MSP430
(F2418. F2618, or F4618) with the CC2x20.
Who is it suitable for?
Post graduates or professors, who want to develop and
analyze the performance of complex networks, where
there is more than one hop, or to analyze the
interoperability of Zigbee products. It is suited for very
low data rate applications. e.g. large area sensor
networks
Compatible Hardware:
- CC2520 DK
- CC243x DK / ZDK
Software Required:
IAR embedded workbench
For more information: www.ti.com/z-stack
For information about ZigBee:
http://www.zigbee.org/
Additional Software
Smart RF Studio
http://focus.ti.com/docs/toolsw/folders/print/smartrftm-studio.html
This application allows you to perform basic transmission
tests and generate register settings for LPRF devices.
Compatible with:
All CCxxxx development kits
TI Flash Programmer
http://www.ti.com/litv/zip/swrc044e
This simple program allows you to use the SmartRF04EB
to place your application into the flash of the SoC.
Compatible with:
CCxx1x / CC243x development kits
IAR Embedded Workbench for 8051
http://www.iar.com
The IAR 8051 compiler is an industry standard compiler
for use with 8051 MCUs. Using this software suite, you
can program the CC SoC with your own application.
Compatible with:
CCxx1x / CC2x3x development kits
Protocols
