For more information on the University Program
http://www.ti.com/europe/university
CC11xx Family & CC25xx Family
Features:
• Configurable Modem
• Data rates up to 500 kbps
• Selectable Modulation techniques:
MSK, FSK, GFSK, ASK and OOK
• Forward Error Correction for increased range
• Hardware support for data whitening
• Hardware support for packet handling and burst
transmissions
• RSSI and LQI calculated
• Wake on Radio
• 64-byte transmit/receive FIFOs
CC2x2x Family & CC2x3x Family
Features:
• Supported by TI’s 802.15.4 MAC and ZigBee stack
• Data rate: 250 kbps
• DSSS (Direct Sequence Spread Spectrum)
• 128(RX) + 128(TX) byte data buffering
• Digital RSSI / LQI support
• Hardware MAC encryption (AES-128)
• Battery monitor
System-on-Chip – CCxx1x, CC2x3x devices
The SoC uses an enhanced 8051 core. This uses the standard
8051 instruction set. Instructions execute faster than the
standard 8051. One clock per instruction cycle is used as
opposed to 12 clocks per instruction cycle in the standard 8051.
Radios
What is included in a development kit?
eZ430 RF Kits
The new eZ430 RF kits provide a complete low-cost develop-
ment platform (shown right). The target board can be
removed for the programmer, and be powered using the
battery adapter. The target boards include a MSP430 MCU,
CC2xxx device (depending on the kit ordered), chip-antenna,
switch and access to the MSP430 pins. Further target boards
can also be ordered separately.
USB Programmer Target Board
EMK
–
Evaluation Module Kit
The EMK normally contains two EM’s and antennae (shown
right). The EM contains the minimum components for a RF
part to function. With a tested RF section, and the complete
pin-out available, it removes the need for RF design when
prototyping.
Note: A SmartRF04EB is required to program the SoC EMs
Above: Two EM’s
Above: eZ430RF2500 USB Dongle
Above: Two SmartRF04EB’s
Above: left- CC2430 BB and EM, right- CC2430DB
DK
–
Development Kit
The development kit contains everything required to fully test
and RF link, and to develop software for the SoC devices.
Most development kits contain two EM’s and two EB’s
(evaluation boards). These evaluation boards allow you to
use our Smart RF Studio software to perform RF tests and
measurements for all devices. They also allow you to
program the SoC devices using our flash programming tools.
The CC2431 DK contains more EM’s and a number of BB’s
(battery boards), which allow you to easily power the SoC
devices.
ZDK
–
Zigbee Development Kit
Like the development kit, the ZDK contains two EM’s and two
EB’s (evaluation boards). The ZDK also contains a number of
DB’s (shown right), which contains a CC2430 and
programmer, and can be USB or battery powered. The DB is
a smaller target board for use in ZigBee applications.
