DS786A1 5
CS4412A
2. CHARACTERISTICS AND SPECIFICATIONS
RECOMMENDED OPERATING CONDITIONS
GND = PGND = 0 V, all voltages with respect to ground.
ABSOLUTE MAXIMUM RATINGS
GND = PGND = 0 V; all voltages with respect to ground.
WARNING: Operation beyond these limits may result in permanent damage to the device. Normal operation is not
guaranteed at these extremes.
Notes: 1. Any pin except supplies. Transient currents of up to ±100 mA on the PWM input pins will not cause
SCR latch-up.
2. The maximum over/under voltage is limited by the input current.
Parameters Symbol Min Nom Max Units
DC Power Supply
Digital Core VD 2.375 2.5 2.625 V
VD 3.135 3.3 3.465 V
VD 4.75 5.0 5.25 V
Power Stage VP 8.0 18.0 V
Temperature
Ambient Temperature Commercial T
A
-10 - +70 °C
Junction Temperature T
J
-10 - +125 °C
Parameters Symbol Min Max Units
DC Power Supply
Power Stage Outputs Switching and Under Load
Power Stage No Output Switching
Digital Core
VP
VP
VD
-0.3
-0.3
-0.3
19.8
23.0
6.0
V
V
V
Inputs
Input Current (Note 1)I
in
-±10mA
Digital Input Voltage (Note 2)V
IND
-0.3 VD + 0.4 V
Temperature
Ambient Operating Temperature - Power Applied
Commercial T
A
-20 +85 °C
Storage Temperature T
stg
-65 +150 °C
