Pin Description
Pin
Description
Name Description Application Information
SOIC-8 LLP-10
1 1 IN_REF Ground reference for control
inputs
Connect to V
EE
for standard positive only output
voltage swing. Connect to system logic ground
reference for positive and negative output voltage
swing.
2 2 IN_A ‘A’ side control input TTL compatible thresholds.
33V
EE
Power ground of the driver
outputs
Connect to either power ground or a negative gate
drive supply.
4 4 IN_B ‘B’ side control input TTL compatible thresholds.
5 7 OUT_B Output for the ‘B’ side driver. Capable of sourcing 3A and sinking 5A. Voltage
swing of this output is from V
CC
to V
EE
.
68V
CC
Positive supply Locally decouple to V
EE
and IN_REF.
7 9 OUT_A. Output for the ‘A’ side driver. Capable of sourcing 3A and sinking 5A. Voltage
swing of this output is from V
CC
to V
EE
.
8 10 nSHDN Shutdown input pin Pull below 1.5V to activate low power shutdown
mode.
Note: Pins 5 and 6 are No Connect for LLP-10 package.
Configuration Table
Part Number “A” Output Configuration “B” Output Configuration Package
LM5110-1M Non-Inverting Non-Inverting SOIC- 8
LM5110-2M Inverting Inverting SOIC- 8
LM5110-3M Inverting Non-Inverting SOIC- 8
LM5110-1SD Non-Inverting Non-Inverting LLP-10
LM5110-2SD Inverting Inverting LLP-10
LM5110-3SD Inverting Non-Inverting LLP-10
LM5110
www.national.com 4
