Tape and Packing
1. Components description (Only for reference)
2. Taping dimensions
Note) Feed holes might be cover with the adhesive tape, but nothing will affect for using by that.
3. Tape and packing specification
3-1. Direction of tape winding
Connection (3) comes to feeding hole side. The direction shall be one in a reel.
3-2. Cumulative pitch tolerance
The cumulative pitch tolerance of the mold for producing the carrier tape shall be within ±0.2mm
per 10pitches.
3-3. The minimum radius to bend the carrier tape
Carrier tape shall be flexible enough to protect from no component and damage under a minimum
radius of 30mm. However it shall be defined only inside of carrier tape．
3-4. The material of carrier tape
Special carbon paints are coated both sides of polystyrene.
3-5. Failure Rate
Type
TL
Discontinuous missing
Product
Package
Transistor / MOSFET
Continuous missing
Remark
Except leader and trail portion
SOT-416 (EMT3)
Incidence
0%
Max.0.1%／reel
Unit ： mm
1.6
1.6
0.8
0.2
0.15
0.7
2.0±0.05
4.0±0.1
4.0±0.1
1.8±0.08
Φ0.5±0.1
0.9±0.2
0.3±0.1
8.0±0.2
3.5±0.05
1.8±0.08
1.75±0.1
5.5±0.2
0～0.5
Φ1.5
+0.1
-0
Unit : mm
(2)
(3)
(1)
www.rohm.com
©2016 ROHM Co., Ltd. All rights reserved
1/4
2016.1 - Rev.A
