Finisar Corporation - June 2015 Rev. B Page 1
Product Specification
10Gb/s 850nm Multimode Datacom SFP+ Transceiver
FTLX8574D3BCL
PRODUCT FEATURES
• Hot-pluggable SFP+ footprint
• Supports 9.95 to 10.5 Gb/s bit
rates*
• Power dissipation < 1W
• RoHS-6 compliant (lead-free)
• Commercial temperature range
-5°C to 70°C
• Single 3.3Vpower supply
• Maximum link length of 400m on
OM4 MMF
• Uncooled 850nm VCSEL laser
• Receiver limiting electrical
interface
• Duplex LC connector
• Built-in digital diagnostic functions
APPLICATIONS
• 10GBASE-SR/SW 10G Ethernet
• 1200-Mx-SN-I 10G Fibre Channel
Finisar’s FTLX8574D3BCL 10Gb/s SFP+ transceivers are designed for use in 10-Gigabit
Ethernet links over multimode fiber. They are compliant with SFF-8431
1
, SFF-8432
2
,
IEEE 802.3-2012 10GBASE-SR/SW
3
and 10G Fibre Channel 1200-Mx-SN-I
4
. Digital
diagnostics functions are available via a 2-wire serial interface, as specified in SFF-
8472
5
. The FTLX8574D3BCL is a “limiting module”, i.e., it employs a limiting receiver.
Host board designers using an EDC PHY IC should follow the IC manufacturer’s
recommended settings for interoperating the host-board EDC PHY with a limiting
receiver SFP+ module. The optical transceiver is compliant per the RoHS Directive
2011/65/EU
6
. See Finisar Application Note AN-2038
7
for more details.
PRODUCT SELECTION
FTLX8574D3BCL
*Contact Finisar for higher data-rate support up to 11.1Gbps.
