2
[Uc] control circuit volt-
age
220 V AC 50/60 Hz
Connections - terminals Control circuit: ring lugs - external diameter: 8 mm
Control circuit: screw clamp terminal 1 cable 1...4
mm² - cable stiffness: flexible - without cable end
Control circuit: screw clamp terminal 2 cable 1...4
mm² - cable stiffness: flexible - without cable end
Control circuit: screw clamp terminal 2 cable 1...2.5
mm² - cable stiffness: flexible - with cable end
Control circuit: screw clamp terminal 1 cable 1...4
mm² - cable stiffness: solid - without cable end
Control circuit: screw clamp terminal 2 cable 1...4
mm² - cable stiffness: solid - without cable end
Power circuit: screw clamp terminal 1 cable 4...50
mm² - cable stiffness: flexible - without cable end
Power circuit: screw clamp terminal 2 cable 4...25
mm² - cable stiffness: flexible - without cable end
Power circuit: screw clamp terminal 1 cable 4...50
mm² - cable stiffness: flexible - with cable end
Power circuit: screw clamp terminal 2 cable 4...16
mm² - cable stiffness: flexible - with cable end
Power circuit: screw clamp terminal 1 cable 4...50
mm² - cable stiffness: solid - without cable end
Power circuit: screw clamp terminal 2 cable 4...25
mm² - cable stiffness: solid - without cable end
Control circuit: screw clamp terminal 1 cable 1...2.5
mm² - cable stiffness: flexible - with cable end
Power circuit: ring lugs - external diameter: 17 mm
Complementary
Coil technology Without built-in bidirectional peak limiting diode suppressor
Protective cover With
Auxiliary contacts type Type mechanically linked (1 NO + 1 NC) conforming to IEC 60947-5-1
Type mirror contact (1 NC) conforming to IEC 60947-4-1
Auxiliary contact composition 1 NO + 1 NC
Control circuit voltage limits 0.3...0.6 Uc at 55 °C drop-out 50/60 Hz
0.8...1.1 Uc at 55 °C operational 50 Hz
0.85...1.1 Uc at 55 °C operational 60 Hz
[Ui] rated insulation voltage 1000 V for power circuit conforming to IEC 60947-1
600 V for control circuit certifications CSA
600 V for control circuit certifications UL
600 V for power circuit certifications CSA
600 V for power circuit certifications UL
690 V for control circuit conforming to IEC 60947-1
[Uimp] rated impulse withstand voltage 8 kV conforming to IEC 60947
Overvoltage category III
Mounting support Plate
Rail
Flame retardance V1 conforming to UL 94
Tightening torque Control circuit: 1.2 nm - on screw clamp terminal - with screwdriver flat Ø 6 mm
Control circuit: 1.2 N.m - on screw clamp terminal - with screwdriver Philips No 2
Power circuit: 9 nm - on 1 entry connector - with screwdriver flat Ø 6 to Ø 8 mm
hexagonal
[Ue] rated operational voltage <= 1000 V AC 25...400 Hz for power circuit
[Ith] conventional free air thermal current 10 A at <= 60 °C for control circuit
125 A at <= 60 °C for power circuit
Irms rated making capacity 1100 A at 440 V for power circuit conforming to IEC 60947
140 A AC for control circuit conforming to IEC 60947-5-1
Rated breaking capacity 1100 A at 440 V for power circuit conforming to IEC 60947
Associated fuse rating 10 A gG for control circuit conforming to IEC 60947-5-1
160 A gG at <= 690 V coordination type 2 for power circuit
200 A gG at <= 690 V coordination type 1 for power circuit
Average impedance 0.8 mOhm at 50 Hz - Ith 125 A for power circuit
Power dissipation per pole 5.1 W AC-3
12.5 W AC-1
Inrush power in VA 245 VA at 20 °C (cos φ 0.75)
Hold-in power consumption in VA 26 VA at 20 °C (cos φ 0.3) 50 Hz
26 VA at 20 °C (cos φ 0.3) 60 Hz
