3 极接触器，带螺钉夹或焊接端子接触器有 440V 交流切换电压和线圈消耗为（交流线圈额定值 50 / 60Hz）4.5VA（保持）和 30VA（涌入）。使用类别 AC3 DIN 导轨或螺钉安装 环境空气温度范围 -25 至 +50°C ### 认可CSA, UL, NEMKO, DEMKO, SEMKO, FIMKO### 标准BS5424 第 1 部分/IEC 947，VDE 0660, NFC63 110### Schneider Electric K 系列
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
封装尺寸在P1P2P3P4P5P6P7P8P9P10P11P12
功能描述在P22
导航目录
LC1K0610E7数据手册
Page:
of 26 Go
若手册格式错乱，请下载阅览PDF原文件
2/20
Schneider Electric
2
2.2
Contactors
Contactors and reversing contactors
types LC
p
-K and LP
p
-K
(1) For mains supplies with a high level of interference (voltage surge > 800 V), use a suppressor module LA4-KE1FC
(50…129 V) or LAF-KE1UG (130…250 V), see page 2/38.
Control circuit characteristics
Contactor type LC1 LC2 LC7 LC8 LP1 LP2
Rated control circuit voltage
(Uc)
V
a
12…690 (1)
a
24…240
c
12…250 (1)
Control voltage limits
Operation 0.8…1.15 Uc 0.85…1.1 Uc 0.8…1.15 Uc
(
≤
50 ˚C) single voltage coil
Drop-out
≥
0.20 Uc
≥
0.10 Uc
≥
0.10 Uc
Average consumption
Inrush 30 VA 3 VA 3 W
at 20 ˚C and at Uc
Sealed 4.5 VA 3 VA 3 W
Heat dissipation W
1.3 3 3
Operating time
Between coil energisation and:
at 20 ˚C and at Uc - opening of the N/C contacts
ms
5…15 25…35 25…35
- closing of the N/O contacts
ms
10…20 30…40 30…40
Between coil de-energisation and:
- opening of the N/O contacts
ms
10…20 30 10
- closing of the N/C contacts
ms
15…25 40 15
Maximum immunity to
micro-breaks ms
2 2 2
Maximum operating rate
In operating cycles per hour 3600 3600 3600
Mechanical durability at Uc
50/60 Hz coil 10 5 10 5 – –
In millions of operating cycles
c
coil – – – – 10 5
Characteristics
(continued)
Selection:
pages 1/12 to 1/35
References:
pages 2/22 to 2/35
Dimensions:
pages 2/40 and 2/42
Schemes:
pages 2/41 and 2/43
22005_Ver8.00-EN.backup.fm Page 20 Thursday, October 25, 2001 5:00 PM
