2
Associated fuse rating 63 A gG at <= 690 V coordination type 2 for power
circuit
63 A gG at <= 690 V coordination type 1 for power
circuit
10 A gG for signalling circuit conforming to IEC
60947-5-1
Average impedance 2 mOhm at 50 Hz - Ith 50 A for power circuit
[Ui] rated insulation
voltage
600 V for signalling circuit certifications UL
600 V for signalling circuit certifications CSA
690 V for signalling circuit conforming to IEC
60947-1
600 V for power circuit certifications UL
600 V for power circuit certifications CSA
690 V for power circuit conforming to IEC 60947-4-1
Electrical durability 1.4 Mcycles 50 A AC-1 at Ue <= 440 V
1.65 Mcycles 32 A AC-3 at Ue <= 440 V
Power dissipation per
pole
5 W AC-1
2 W AC-3
Safety cover With
Interlocking type Mechanical
Mounting support Plate
Rail
Standards EN 60947-4-1
EN 60947-5-1
IEC 60947-4-1
IEC 60947-5-1
UL 508
CSA C22.2 No 14
Product certifications BV
CCC
CSA
DNV
GL
GOST
RINA
UL
LROS
Connections - terminals Power circuit: screw clamp terminals 2 cable(s)
2.5...10 mm² - cable stiffness: solid - without cable
end
Power circuit: screw clamp terminals 1 cable(s)
1.5...10 mm² - cable stiffness: solid - without cable
end
Power circuit: screw clamp terminals 2 cable(s)
1.5...6 mm² - cable stiffness: flexible - with cable end
Power circuit: screw clamp terminals 1 cable(s)
1...10 mm² - cable stiffness: flexible - with cable end
Power circuit: screw clamp terminals 2 cable(s)
2.5...10 mm² - cable stiffness: flexible - without cable
end
Power circuit: screw clamp terminals 1 cable(s)
2.5...10 mm² - cable stiffness: flexible - without cable
end
Control circuit: screw clamp terminals 2 cable(s)
1...4 mm² - cable stiffness: solid - without cable end
Control circuit: screw clamp terminals 1 cable(s)
1...4 mm² - cable stiffness: solid - without cable end
Control circuit: screw clamp terminals 2 cable(s)
1...2.5 mm² - cable stiffness: flexible - with cable end
Control circuit: screw clamp terminals 1 cable(s)
1...4 mm² - cable stiffness: flexible - with cable end
Control circuit: screw clamp terminals 2 cable(s)
1...4 mm² - cable stiffness: flexible - without cable
end
Control circuit: screw clamp terminals 1 cable(s)
1...4 mm² - cable stiffness: flexible - without cable
end
Tightening torque Power circuit: 2.5 N.m - on screw clamp terminals -
with screwdriver Philips No 2
Power circuit: 2.5 N.m - on screw clamp terminals -
with screwdriver flat Ø 6 mm
Control circuit: 1.7 N.m - on screw clamp terminals -
with screwdriver Philips No 2
Control circuit: 1.7 N.m - on screw clamp terminals -
with screwdriver flat Ø 6 mm
