Texas Instruments, Inc. PCN# 20160321001
Type
Test Name / Condition
Duration
QBS Package Reference:
LM324ADR
QBS Package Reference:
LM358DR
QBS Package Reference:
LM393DR
AC
Autoclave 121C
96 Hours
3/231/0
3/231/0
3/231/0
HTSL
High Temp. Storage Bake,
170C
420 Hours
3/229/0
3/229/0
3/231/0
DS
Die Shear
--
3/30/0
3/30/0
3/30/0
FLAM
Flammability (IEC 695-2-2)
--
3/15/0
3/15/0
3/15/0
FLAM
Flammability (UL 94V-0)
--
3/15/0
3/15/0
3/15/0
FLAM
Flammability (UL-1694)
--
3/15/0
3/15/0
3/15/0
HAST
Biased HAST, 130C/85%RH
96 Hours
3/231/0
3/231/0
3/231/0
HTOL
Life Test, 150C
300 Hours
3/231/0
3/231/0
-
LI
Lead Fatigue
Leads
3/66/0
3/66/0
3/66/0
LI
Lead Pull to Destruction
Leads
3/66/0
3/66/0
3/66/0
LI
Lead Finish Adhesion
Leads
3/45/0
3/45/0
3/45/0
MISC
Salt Atmosphere
Salt Atmosphere
3/65/0
3/66/0
-
PD
Physical Dimensions
--
3/60/0
3/60/0
3/60/0
SD
Solderability
8 Hours Steam Age
3/66/0
3/66/0
3/66/0
TC
Temperature Cycle, -
65C/150C
500 Cycles
3/231/0
3/230/0
3/231/0
WBP
Bond Pull
Wires
3/228/0
3/228/0
3/228/0
WBS
Ball Bond Shear
Wires
3/228/0
3/228/0
3/228/0
- Preconditioning was performed for Autoclave, Unbiased HAST, THB/Biased HAST, Temperature Cycle, Thermal Shock, and HTSL, as
applicable
- The following are equivalent HTOL options based on an activation energy of 0.7eV : 125C/1k Hours, 140C/480 Hours, 150C/300
Hours, and 155C/240 Hours
- The following are equivalent HTSL options based on an activation energy of 0.7eV : 150C/1k Hours, and 170C/420 Hours
- The following are equivalent Temp Cycle options per JESD47 : -55C/125C/700 Cycles and -65C/150C/500 Cycles
Quality and Environmental data is available at TI's external Web site: http://www.ti.com/
Green/Pb-free Status:
Qualified Pb-Free(SMT) and Green
For questions regarding this notice, e-mails can be sent to the regional contacts shown below
or your local Field Sales Representative.
Location
E-Mail
USA
PCNAmericasContact@list.ti.com
Europe
PCNEuropeContact@list.ti.com
Asia Pacific
PCNAsiaContact@list.ti.com
Japan
PCNJapanContact@list.ti.com
