Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
Differential Input Voltage
±
Supply Voltage
Voltage at Input/Output Pin (V
+
) +0.3V,
(V
−
) −0.3V
Supply Voltage (V
+
−V
−
) 16V
Output Short Circuit to V
+
(Note 11)
Output Short Circuit to V
−
(Note 2)
Lead Temperature
(Soldering, 10 sec.) 260˚C
Storage Temp. Range −65˚C to +150˚C
Junction Temperature 150˚C
ESD Tolerance (Note 4) 2 kV
Current at Input Pin
±
10 mA
Current at Output Pin
±
30 mA
Current at Power Supply Pin 40 mA
Power Dissipation (Note 3)
Operating Ratings (Note 1)
Temperature Range
LMC6064AM −55˚C ≤ T
J
≤ +125˚C
LMC6064AI, LMC6064I −40˚C ≤ T
J
≤ +85˚C
Supply Voltage 4.5V ≤ V
+
≤ 15.5V
Thermal Resistance (θ
JA
) (Note 12)
14-Pin Molded DIP 81˚C/W
14-Pin SO 126˚C/W
Power Dissipation (Note 10)
DC Electrical Characteristics
Unless otherwise specified, all limits guaranteed for T
J
= 25˚C. Boldface limits apply at the temperature extremes. V
+
= 5V, V
−
= 0V, V
CM
= 1.5V, V
O
= 2.5V and R
L
>
1M unless otherwise specified.
Typ LMC6064AM LMC6064AI LMC6064I
Symbol Parameter Conditions (Note 5) Limit Limit Limit Units
(Note 6) (Note 6) (Note 6)
V
OS
Input Offset Voltage 100 350 350 800 µV
1200 900 1300 Max
TCV
OS
Input Offset Voltage 1.0 µV/˚C
Average Drift
I
B
Input Bias Current 0.010 pA
100 4 4 Max
I
OS
Input Offset Current 0.005 pA
100 2 2 Max
R
IN
Input Resistance
>
10 Tera Ω
CMRR Common Mode 0V ≤ V
CM
≤ 12.0V 85 75 75 66 dB
Rejection Ratio V
+
= 15V 70 72 63 Min
+PSRR Positive Power Supply 5V ≤ V
+
≤ 15V 85 75 75 66 dB
Rejection Ratio V
O
= 2.5V 70 72 63 Min
−PSRR Negative Power Supply 0V ≤ V
−
≤ −10V 100 84 84 74 dB
Rejection Ratio 70 81 71 Min
V
CM
Input Common-Mode V
+
= 5V and 15V −0.4 −0.1 −0.1 −0.1 V
Voltage Range for CMRR ≥ 60 dB 000Max
V
+
− 1.9 V
+
− 2.3 V
+
− 2.3 V
+
− 2.3 V
V
+
− 2.6 V
+
− 2.5 V
+
− 2.5 Min
A
V
Large Signal R
L
= 100 kΩ Sourcing 4000 400 400 300 V/mV
Voltage Gain (Note 7) 200 300 200 Min
Sinking 3000 180 180 90 V/mV
70 100 60 Min
R
L
=25kΩ Sourcing 3000 400 400 200 V/mV
(Note 7) 150 150 80 Min
Sinking 2000 100 100 70 V/mV
35 50 35 Min
LMC6064
www.national.com 2
