AC Electrical Characteristics (Continued)
Note 1: Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for which the device is
intended to be functional, but do not guarantee specific performance limits. For guaranteed specifications and test conditions, see the Electrical Characteristics. The
guaranteed specifications apply only for the test conditions listed.
Note 2: Applies to both single-supply and split-supply operation. Continous short circuit operation at elevated ambient temperature can result in exceeding the
maximum allowed junction temperature of 150˚C. Output currents in excess of
±
30 mA over long term may adversely affect reliability.
Note 3: The maximumpowerdissipationisa function ofT
J(Max)
, θ
JA
, and T
A
. The maximum allowable power dissipation at any ambienttemperatureisP
D
=(T
J(Max)
−T
A
)/θ
JA
.
Note 4: Human body model, 1.5 kΩ in series with 100 pF.
Note 5: Typical values represent the most likely parametric norm.
Note 6: All limits are guaranteed by testing or statistical analysis.
Note 7: V
+
= 15V, V
CM
= 7.5V and R
L
connected to 7.5V. For Sourcing tests, 7.5V ≤ V
O
≤ 11.5V. For Sinking tests, 2.5V ≤ V
O
≤ 7.5V.
Note 8: V
+
= 15V. Connected as Voltage Follower with 10V step input. Number specified is the slower of the positive and negative slew rates.
Note 9: Input referred V
+
= 15V and R
L
= 100 kΩ connected to 7.5V. Each amp excited in turn with 100 Hz to produce V
O
=12V
PP
.
Note 10: For operating at elevated temperatures the device must be derated based on the thermal resistance θ
JA
with P
D
=(T
J
–T
A
)/θ
JA
.
Note 11: Do not connect output to V
+
, when V
+
is greater than 13V or reliability witll be adversely affected.
Note 12: All numbers apply for packages soldered directly into a PC board.
Note 13: For guaranteed Military Temperature Range parameters see RETSMC6064X.
LMC6064
www.national.com 4
