Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
ESD Tolerance (Note 2) 2 KV
Differential Input Voltage (V
+
)+0.3V to (V
−
)−0.3V
Voltage at Input/Output Pin (V
+
)+0.3V to (V
−
)−0.3V
Supply Voltage (V
+
–V
−
) 16V
Current at Input Pin
±
5mA
Current at Output Pin
(Notes 7, 3)
±
30 mA
Current at Power Supply Pin,
LMC6762 40 mA
Lead Temperature
(Soldering, 10 seconds) 260˚C
Storage Temperature Range −65˚C to +150˚C
Junction Temperature (Note
4)
150˚C
Operating Ratings (Note 1)
Supply Voltage 2.7 ≤ V
S
≤ 15V
Junction Temperature Range
LMC6762AI, LMC6762BI −40˚C ≤ T
J
≤ +85˚C
Thermal Resistance (θ
JA
)
N Package, 8-Pin Molded DIP 100˚C/W
M Package, 8-Pin Surface
Mount
172˚C/W
2.7V Electrical Characteristics
Unless otherwise specified, all limits guaranteed for T
J
= 25˚C, V
+
= 2.7V, V
−
= 0V, V
CM
=V
+
/2. Boldface limits apply at the
temperature extremes.
Symbol Parameter Conditions
Typ
(Note 5)
LMC6762AI LMC6762BI Units
Limit Limit
(Note 6) (Note 6)
V
OS
Input Offset Voltage 3 5 15 mV
818max
TCV
OS
Input Offset Voltage 2.0 µV/˚C
Temperature Drift
Input Offset Voltage (Note 8) 3.3 µV/Month
Average Drift
I
B
Input Current 0.02 pA
I
OS
Input Offset Current 0.01 pA
CMRR Common Mode Rejection Ratio 75 dB
PSRR Power Supply Rejection Ratio
±
1.35V
<
V
S
<
±
7.5V 80 dB
A
V
Voltage Gain (By Design) 100 dB
V
CM
Input Common-Mode CMRR
>
55 dB 3.0 2.9 2.9 V
Voltage Range 2.7 2.7 min
−0.3 −0.2 −0.2 V
0.0 0.0 max
V
OH
Output Voltage High I
LOAD
= 2.5 mA 2.5 2.4 2.4 V
2.3 2.3 min
V
OL
Output Voltage Low I
LOAD
= 2.5 mA 0.2 0.3 0.3 V
0.4 0.4 max
I
S
Supply Current For Both Comparators 12 20 20 µA
(Output Low) 25 25 max
LMC6762
www.national.com 2
