Limit and Enclosed Switches LSX Series
Weather-Sealed Explosion-Proof Switches
A116Honeywell1 Sensing and Control11-800-537-6945 USA1F1-815-235-6847 International11-800-737-3360 Canada
OPERATING CHARACTERISTICS
Rotary actuated switches
Side Rotary
Center Top Rotary
Momentary Maintained Sequence Neutral Momentary
LSXP LSXH LSXL LSXM
LSXA Low Diff. LSXR Low Diff. (Double Pole (Double Pole
Standard Travel Low Torque Low Torque LSXN Only) Only) LSXB
Pretravel max. 15° 9° 15° 9° 65° 1st step 15° 18° 25°
2nd step 10°
additional
Overtravel min. 60° 66° 60° 66° 20° 48° 57° 100°
Differential SPDT DPDT SPDT DPDT SPDT DPDT SPDT DPDT SPDT DPDT SPDT DPDT
Travel max. 5° 7° 3° 4° 5° 7° 3° 4° 30° 35° 5° 10° 10° 12°
Operating 0,45 Nm 0,45 Nm 0,19 0,19 Nm 0,45 Nm 0,45 Nm 0,45 Nm 0,28 Nm
Torque max. 4 in. lbs. 4 in. lbs. 1.7 in. lbs. 1.7 in. lbs. 4 in. lbs. 4 in. lbs. 4 in. lbs. 2.5 in. lbs.
Operating 10 to 250°F 30 to 250°F 10 to 250°F 30 to 250°F
Temp. Range – 12 to 121°C –1 to 121°C –12 to 121°C –1 to 121°C
Nm J Newton meters
Plunger actuated switches
Momentary
LSXC LSXD LSXE LSXF
Top Plunger Top Roller Plunger Side Plunger Side Roller Plunger
Pretravel max. 1,78mm 1,78mm 2,54mm 2,54mm
.070 in. .070 in. .100 in. .100 in.
Differential Travel max. SPDT DPDT SPDT DPDT
0,38mm 0,51mm 0,38mm 0,51mm 1,14mm 1,14mm
.015 in. .020 in. .015 in. .020 in. .045 in. .045 in.
Overtravel min. 4,83mm 4,83mm 4,83mm 4,83mm
.190 in. .190 in. .190 in. .190 in.
Operating Force max. 17,8 N 17,8 N 26,7 N 26,7 N
4 lbs. 4 lbs. 6 lbs. 6 lbs.
Operating Point 58,5 ± 0,76mm 68,6 ± 1mm 33,0 ± 0,76mm 44,1 ± 1mm
2.305 ± .030 in. 2.700 ± .040 in. 1.300 ± .030 in. 1.735 ± .040 in.
Operating Temperature Range –12 to 93°C
10 to 200°F
Wobble Actuated Switches
Momentary
LSXJ LSXK Cat Whisker
Delrin Rod (Wire)
Radius approx.
Pretravel max. 25,4mm 50,8mm
1.0 in. 2.0 in.
Operating Force max. 2,78 N 1,39 N
10 oz. 5.0 oz.
Operating Temperature Range –12 to 93°C
10 to 200°F
N J Newtons
COMPLETELY FLUOROCARBON-
SEALED AND LOW TEMPERATURE
SWITCHES
Completely fluorocarbon-sealed and low
temperature construction LSX switches are
available. See page A42 for a full description
of both of these options.
How to order
For fluorocarbon-sealed switches, insert
the additional letters Y and C in the appropri-
ate places in the standard catalog listing; for
low temperature versions insert the addi-
tional letters Y and B. Examples follow:
LSXA3K—standard side rotary switch
LSXYAC3K—completely fluorocarbon-
sealed version of the LSXA3K
LSXA3K—standard side rotary switch
LSXYAB3K—low temperature version of
the LSXA3K
