LT1461
3
Rev. C
For more information www.analog.com
ELECTRICAL CHARACTERISTICS
AVAILABLE OPTIONS
ORDER INFORMATION
PARAMETER CONDITIONS MIN TYP MAX UNITS
Output Voltage (Note 4) LT1461ACS8/LT1461AIS8
LT1461BCS8/LT1461BIS8
LT1461CCS8/LT1461CIS8
LT1461DHS8
–0.04
–0.06
–0.08
–0.15
0.04
0.06
0.08
0.15
%
%
%
%
Output
Voltage Temperature Coefficient (Note 5) LT1461ACS8/LT1461AIS8
LT1461BCS8/LT1461BIS8
LT1461CCS8/LT1461CIS8
LT1461DHS8
l
l
l
l
1
3
5
7
3
7
12
20
ppm
/°C
ppm/°C
ppm/°C
ppm/°C
The l denotes the specifications which apply over the specified
temperature range, otherwise specifications are at T
A
= 25°C. V
IN
– V
OUT
= 0.5V, Pin 3 = 2.4V, C
L
= 2µF, unless otherwise specified.
LEAD FREE FINISH TAPE AND REEL PART MARKING PACKAGE DESCRIPTION SPECIFIED TEMPERATURE RANGE
LT1461CIS8-4#PBF LT1461CIS8-4#TRPBF 461CI4 8-LEAD PLASTIC SO –40°C to 85°C
LT1461CIS8-5#PBF LT1461CIS8-5#TRPBF 461CI5 8-LEAD PLASTIC SO –40°C to 85°C
LT1461DHS8-2.5#PBF LT1461DHS8-2.5#TRPBF 61DH25 8-LEAD PLASTIC SO –40°C to 125°C
LT1461DHS8-3#PBF LT1461DHS8-3#TRPBF 461DH3 8-LEAD PLASTIC SO –40°C to 125°C
LT1461DHS8-3.3#PBF LT1461DHS8-3.3#TRPBF 61DH33 8-LEAD PLASTIC SO –40°C to 125°C
LT1461DHS8-4#PBF LT1461DHS8-4#TRPBF 461DH4 8-LEAD PLASTIC SO –40°C to 125°C
LT1461DHS8-5#PBF LT1461DHS8-5#TRPBF 461DH5 8-LEAD PLASTIC SO –40°C to 125°C
AUTOMOTIVE PRODUCTS**
LT1461DHS8-2.5#WPBF LT1461DHS8-2.5#WTRPBF 61DH25 8-LEAD PLASTIC SO –40°C to 125°C
LT1461DHS8-3#WPBF LT1461DHS8-3#WTRPBF 461DH3 8-LEAD PLASTIC SO –40°C to 125°C
LT1461DHS8-3.3#WPBF LT1461DHS8-3.3#WTRPBF 61DH33 8-LEAD PLASTIC SO –40°C to 125°C
LT1461DHS8-4#WPBF LT1461DHS8-4#WTRPBF 461DH4 8-LEAD PLASTIC SO –40°C to 125°C
LT1461DHS8-5#WPBF LT1461DHS8-5#WTRPBF 461DH5 8-LEAD PLASTIC SO –40°C to 125°C
Contact the factory for parts specified with wider operating temperature ranges. *The temperature grade is identified by a label on the shipping container.
Tape and reel specifications. Some packages are available in 500 unit reels through designated sales channels
with #TRMPBF suffix.
**
Versions of this part are available with controlled manufacturing to support the quality and reliability requirements of automotive applications. These
models are designated with a #W suffix. Only the automotive grade products shown are available for use in automotive applications. Contact your
local Analog Devices account representative for specific product ordering information and to obtain the specific Automotive Reliability reports for
thesemodels.
INITIAL
ACCURACY
TEMPERATURE
COEFFICIENT
TEMPERATURE
RANGE
OUTPUT VOLTAGE
2.5V 3.0V 3.3V 4.096V 5.0V
0.04% Max 3ppm/°C Max 0°C to 70°C LT1461ACS8-2.5 LT1461ACS8-3 LT1461ACS8-3.3 LT1461ACS8-4 LT1461ACS8-5
0.04% Max 3ppm/°C Max –40°C to 85°C LT1461AIS8-2.5 LT1461AIS8-3 LT1461AIS8-3.3 LT1461AIS8-4 LT1461AIS8-5
0.06% Max 7ppm/°C Max 0°C to 70°C LT1461BCS8-2.5 LT1461BCS8-3 LT1461BCS8-3.3 LT1461BCS8-4 LT1461BCS8-5
0.06% Max 7ppm/°C Max –40°C to 85°C LT1461BIS8-2.5 LT1461BIS8-3 LT1461BIS8-3.3 LT1461BIS8-4 LT1461BIS8-5
0.08% Max 12ppm/°C Max 0°C to 70°C LT1461CCS8-2.5 LT1461CCS8-3 LT1461CCS8-3.3 LT1461CCS8-4 LT1461CCS8-5
0.08% Max 12ppm/°C Max –40°C to 85°C LT1461CIS8-2.5 LT1461CIS8-3 LT1461CIS8-3.3 LT1461CIS8-4 LT1461CIS8-5
0.15% Max 20ppm/°C Max –40°C to 125°C LT1461DHS8-2.5 LT1461DHS8-3 LT1461DHS8-3.3 LT1461DHS8-4 LT1461DHS8-5
