Datasheet 搜索 > EEPROM芯片 > ST Microelectronics（意法半导体） > M24C04-DRDW3TP/K 数据手册 > M24C04-DRDW3TP/K 其他数据使用手册 1/43 页
器件3D模型￥ 2.61
M24C04-DRDW3TP/K 其他数据使用手册 - ST Microelectronics（意法半导体）
制造商:
ST Microelectronics（意法半导体）
分类:
EEPROM芯片
封装:
TSSOP-8
描述:
EEPROM, 4 Kbit, 512 x 8位, 串行I2C (2-线), 1 MHz, TSSOP, 8 引脚
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
导航目录
M24C04-DRDW3TP/K数据手册
Page:
of 43 Go
若手册格式错乱，请下载阅览PDF原文件
This is information on a product in full production.
January 2017 DocID027421 Rev 2 1/42
M24C04-DRE
4-Kbit serial I²C bus EEPROM - 105°C operation
Datasheet - production data
Features
• Compatible with all I
2
C bus modes
–1 MHz
– 400 kHz
– 100 kHz
• Memory array
– 4 Kbits (512 bytes) of EEPROM
– Page size: 16 bytes
– Additional Write lockable page
(Identification page)
• Extended temperature and voltage range
– -40 °C to 105 °C; 1.7 V to 5.5 V
• Schmitt trigger inputs for noise filtering
• Short Write cycle time
– Byte Write within 4 ms
– Page Write within 4 ms
• Write cycle endurance
– 4 million Write cycles at 25 °C
– 1.2 million Write cycles at 85 °C
– 900 k Write cycles at 105 °C
• Data retention
– more than 50 years at 105 °C
– 200 years at 55 °C
• ESD Protection (Human Body Model)
– 4000 V
• Packages
– RoHS compliant and halogen-free
(ECOPACK2
®
)
SO8 (MN)
TSSOP8 (DW)
WFDFPN8 (MF)
DFN8 - 2 x 3 mm
169 mil width
150 mil width
www.st.com
