General Description
The MAX3421 evaluation kit-1 (EV kit-1) provides a
proven design to evaluate the MAX3421E USB periph-
eral controller with SPI™ interface. The EV kit contains
both a MAX3421E USB host & peripheral controller and
a MAX3420E USB peripheral controller for user evalua-
tion and development. Connector J4 is wired to plug
into a Keil MCB2130 development board that contains
a Philips ARM controller (LPC2318). The design uses
two separate SPI ports to provide independent opera-
tion of the two USB controllers (MAX3421E and
MAX3420E).
The MAX3421 EV kit-1 adds USB functionality to any
microcontroller, microprocessor, DSP, CPLD, FPGA, or
ASIC with an SPI master interface, or five GPIO lines.
The EV kit-1 board comes with the MAX3421EEHJ+
and MAX3420EECJ+ installed.
Features
♦ Ideal USB Training and Debugging System
♦ Mates to Keil MCB2130 Development Board
♦ Can Be Wired into User Systems
♦ MAX3421E Can Be Used as a USB Host or
Peripheral
♦ MAX3420E Provided On-Board as a Test
Peripheral
♦ MAX3420E Can be Used to Develop USB
Peripheral Code
Evaluates: MAX3421E/MAX3420E
MAX3421 Evaluation Kit-1
________________________________________________________________
Maxim Integrated Products
1
19-0697; Rev 0; 12/06
Component List
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
Ordering Information
SPI is a trademark of Motorola, Inc.
+
Denotes a lead-free and RoHS-compliant EV kit.
PART NUMBER TYPE PC INTERFACE
MAX3421EVKIT-1+ EV kit USB
DESIGNATION QTY DESCRIPTION
C1, C3, C5, C6,
C8, C9
6
2.2µF ±10%, 10V X5R ceramic
capacitors (0805)
TDK C2012X5R1A225KB
C2, C4, C7,
C10
4
1µF ±10%, 16V X5R ceramic
capacitors (0603)
TDK C1608X5R1C105K
C11–C14 0
Not installed, 18pF ±5%, 50V C0G
ceramic capacitors (0402)
TDK C1005C0G1H180J
C15 1
0.1µF, 5V (min) X7R ceramic
capacitor (0603)
TDK C1608X7R1C104K,
C1608X7R1E104K, or
C1608X7R1H104K
Panasonic-ECG ECJ-1VB1C104K
KEMET C0603C104K3RAC
AVX 0603ZC104KAT
D1–D4 4
Green LEDs (0805)
Lumex Opto SML-LX0805UPGC-TR
D5 1
7-segment LED display,
common-cathode
LITE-ON LSHD-7503
DESIGNATION QTY DESCRIPTION
J1 1
USB type A right-angle receptacle
Assmann Electronic AU-Y1006-R
J2, J5 2
USB type B right-angle receptacles
Assmann Electronic AU-Y1007-R
J3 1 3-pin header
J4 1 2 x 18 right-angle female receptacle
PB1–PB8 8
6mm light-touch switches with
GND (H = 7)
Panasonic-ECG EVQ-PBC07K
R1–R4 4 33Ω ±5% resistors (0603)
R5–R16 12 470Ω ±5% resistors (0603)
R17, R18 2 2.2kΩ ±5% resistors (0603)
U1 1
MAX3421EEHJ+ USB peripheral/host
controller with SPI interface (32-pin,
5mm x 5mm, TQFP)
U2 1
MAX3420EECJ+ USB peripheral
controller with SPI
interface (32-pin, 7mm x 7mm, TQFP)
