TM
Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc in the US and other countries. All other product or service names are the
property of their respective owners. © Freescale Semiconductor, Inc. 2008. The information provided is typical to the industry and is not intended to represent
actual practice at Freescale.
Substrate with
Soldermask
Epoxy Overmold
Routing Vias
Solder Sphere
Silicon Die
Die Attach
Au Bond Wires
Ball Pitch
Motherboard
Solder Pads (PBGA Package Pads
- PCB Pad)
Joint Stand-Off
(Varies with Pad
Sizes, Sphere
Sizes and Solder
Paste Volume)
PBGA BGA Construction
Thermal and/or
Ground Vias
PBGA Introduction and Package Description
“MAP” Style
PBGA Molded
to Substrate Edge
