March 20, 1997 5:12 pm
Page 5 of 13
MC68302 Document
66 90 Clock on which BGACK low to clock on
which AS low
tclbklal
2 clks
2 clks
67 91 Clock high to BGACK high tchbkh
-
15
68 92 Clock low to BGACK hi-z tclbkz
-
10
69 93 Clock high to DACK low tchackl
-
15
70 94 Clock low to DACK high tclackh
-
15
71 95 Clock high to DONE low (output) tchdnl
-
15
72 96 Clock low to DONE hi-z tcldnz
-
15
73 97 DONE input low to clock high tdnltch
10
-
74 100 RW valid to DS low trwvdsl
0
-
75 101 DS low to Data-in valid tdsldiv
-
15
76 102 DTACK low to Data in hold time tdkldh
0
-
77 103 AS valid to DS low tasvdsl
0
-
78 104 DTACK low to AS, DS high tdkldsh
0
-
79 105 DS high to DTACK high tdshdkh
-
25
80 106 DS inactive to AS inactive tdsiasi
0
-
81 107 DS high to RW high tdshrwh
0
-
82 108 DS high to data hi-z tdshdz
-
25
Table 1:
#
Spec
No.
Description
Spec Name
UM
33MHz
Min
33MHz
Max
Frees
cale Semiconductor,
I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...
