MC9S08JM32CGT 产品描述及参数 - NXP（恩智浦）
制造商:
NXP（恩智浦）
分类:
微控制器
封装:
QFN-48
描述:
NXP MC9S08JM32CGT 芯片, 微控制器, 8位, S08, 32K闪存, QFN48
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
原理图在P1
应用领域在P1
导航目录
MC9S08JM32CGT数据手册
Page:
of 2 Go
若手册格式错乱，请下载阅览PDF原文件
Target Applications
Overview
The 8-bit MC9S08JM16 device further extends
Freescale’s entry-level 8-bit embedded
USB controller family with up to 16 KB of
flash memory, a full-speed USB 2.0 device
controller and an eight-channel, 12-bit
analog-to-digital converter. The S08 JM family
also has several system protection features,
such as low voltage detection and a computer
operating properly (COP) module.
The MC9S08JM16 device is well suited
for a variety of industrial control and
consumer applications. Such applications
include PC peripherals, industrial printers
and touch panels.
The MC9S08JM16 devices, like the other USB
microcontrollers in the Controller Continuum,
are supported by the Freescale USB-LITE
Stack by CMX. This complimentary USB stack
provides support for certain HID and CDC
classes. Source code for the complimentary
stack is available.
The MC9S08JM16 is software compatible
with other devices in the Controller
Continuum, providing a direct migration path
to higher performing USB microcontrollers.
8-bit S08 embedded controllers
MC9S08JM16
8-bit USB microcontroller
MC9S08JM16 Block Diagram
2 SCI
1K RAM
256 Byte
USB RAM
S08 Core
Flash Memory
16K Flash
Flash Memory
Options
8K Flash
ICE + BDM
KBI
2 SPI
Independent
Clocked COP
I
2
C
RTC
Full-Speed
USB 2.0 Device
4-ch., 16-bit
Timer
Comparator
2-ch., 16-bit
Timer
MCG
8-ch., 12-bit
ADC
Features Benefits
8-bit HCS08 Central Processing Unit (CPU)
• Up to 24 MHz internal bus (48 MHz HCS08
core) frequency offering 2.7 to 5.5V across
temperature range of -40°C to +85°C
• Offers strong performance throughout the entire
voltage range
• Support for up to 32 peripheral interrupt/
request resources
• Allows for exceptional software flexibility and
optimization for real-time applications
On-Chip Memory
• Up to 16K flash read/program/erase over full
operating voltage and temperature
• Allows user to take full advantage of in-application,
re-programmability benefits
• Up to 1K RAM
• Security circuitry to help prevent unauthorized
access to RAM
• Flash contents help to reduce system power
consumption
• 256 Byte USB RAM
• Improve data transfer speed by providing
data buffering
Power-Saving Modes
• Wait plus two stop modes
• Allows continuation of sampling application in a reduced
power state which reduces system power consumption
• Multi-purpose clock generator (MCG) • Frequency-locked loop (FLL): Internal or external
reference can be used to control the FLL
• Phase-locked loop (PLL): Voltage controlled
oscillator (VCO). Modulo VCO frequency divider.
Lock detector with interrupt capability
• Internal reference clock: Can be selected as the
clock source for the MCU
• External reference clock: Provides control for
a separate crystal oscillator. Clock monitor with
reset capability. Can be selected as the clock
source for the MCU.
• Reference divider provided
• Clock source can be divided by 1, 2, 4 or 8
Peripherals
• USB device module
• Full-speed USB 2.0 (12 Mbps) module with
dedicated on-chip 3.3V regulator
• Supports control, interrupt, isochronous and
bulk transfers
• PC peripherals
• Uninterrupted
power supplies
• Touch panels
• Gamepads
• Label printers
• Remote controls
• I/O modules
• Industrial
networking
products
• Stationary
barcode scanners
• Barcode scanners
• Utility meters
• Industrial printers
• Data loggers
• Automatic drug
dispensers
• Motion controllers
• Laboratory
equipment
• Lighting control
systems
• Security control
panels
• Cash register
printers
• Measurement
equipment
