MC9S12A64CFUE 其他数据使用手册 - Freescale（飞思卡尔）
制造商:
Freescale（飞思卡尔）
分类:
微控制器
封装:
QFP-80
描述:
S12A/D 系列微控制器装置S12A/D 系列为 16 位微控制器装置 (MCU)，也可为低成本系统连接单 8 位宽内存。 该集成 PLL 电路提供功耗和性能灵活性，以满足用户的操作要求。 S12A/D 微控制器装置包括以下标准芯片外围设备； HCS12 CPU 64 K 字节闪存 EEPROM 1 K 字节 EEPROM 4 K 字节 RAM 2 个异步串行通信接口 (SCI) 1 个串行外围接口 (SPI) 8 通道 IC/OC 增强型捕获计时器 2 个 8 通道 10 位模拟至数字转换器 (ADC) 8 通道脉冲宽度调制器 (PWM) 数字字节数据链接控制器 (BDLC) 29 个分离式数字 I/O 通道 20 个分离式数字 I/O 线路 可与 CAN 软件兼容的模块 Byteflight 模块 I2C 总线### S12 微控制器，FreescaleFreescale S12 微控制器是高性能的 16 位设备，用于汽车和工业应用。
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
导航目录
MC9S12A64CFUE数据手册
Page:
of 128 Go
若手册格式错乱，请下载阅览PDF原文件
Motorola reserves the right to make changes without further notice to any products herein to improve reliability, function or
design. Motorola does not assume any liability arising out of the application or use of any product or circuit described herein;
neither does it convey any license under its patent rights nor the rights of others. Motorola products are not designed, intended,
or authorized for use as components in systems intended for surgical implant into the body, or other applications intended to
support or sustain life, or for any other application in which the failure of the Motorola product could create a situation where
personal injury or death may occur. Should Buyer purchase or use Motorola products for any such unintended or unauthorized
application,BuyershallindemnifyandholdMotorolaanditsofficers,employees,subsidiaries,affiliates,anddistributorsharmless
against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of
personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that Motorola was
negligent regarding the design or manufacture of the part.
DOCUMENT NUMBER
9S12DJ64DGV1/D
1
MC9S12DJ64
Device User Guide
V01.20
Covers also
MC9S12D64, MC9S12A64, MC9S12D32,
MC9S12A32
Original Release Date: 19 Nov. 2001
Revised: 6 April 2005
Motorola, Inc.
