i.MX28 Applications Processors for Consumer Products, Rev. 3
4 Freescale Semiconductor
Introduction
Table 2 provides the functional differences between the i.MX280, i.MX283, i.MX286, and i.MX287.
Table 2. i.MX28 Functional Differences
Function i.MX280 i.MX283 i.MX286 i.MX287
Application UART x5 x5 x5 x5
Debug UART x1 x1 x1 x1
CAN — — x2 x2
Ethernet x1 x1 x1 x2
High-speed ADC x1 x1 x1 x1
L2 Switch — — — Yes
LCD Interface — Yes Yes Yes
LRADC
1
1
There are 16 physical channels but they can only be mapped to 8 virtual channels at a time.
x8 x8 x8 x8
PWM x8 x8 x8 x8
S/PDIF Tx — — Yes Yes
SD/SDIO/MMC
2
2
For SD/SDIO/MMC, four synchronous serial ports (SSP) are available: SSP0, SSP1, SSP2, and SSP3. SSP0 and SSP1 can
support three modes,1-bit, 4-bit, and 8-bit, whereas SSP2 and SSP3 can support only 1-bit and 4-bit modes.
x4 x4 x4 x4
S e c u r i t y Ye s Ye s Ye s Ye s
SPI x4 x4 x4 x4
Touch Screen — Yes Yes Yes
USB 2.0 OTG HS with
HS PHY x1
OTG HS with HS PHY x1 OTG HS with HS PHY x1 OTG HS with HS PHY x1
HS Host with
HS PHY x1
HS Host with HS PHY x1 HS Host with HS PHY x1 HS Host with HS PHY x1
