Chip Errata for the i.MX 6ULL, Rev. 1.1, 05/2017
NXP Semiconductors 3
ERR008961 ARM/MP: 804069—C Exception mask bits are cleared when an exception is
taken in Hyp Mode
No fix scheduled
9
CCM
ERR007265 CCM: When improper low-power sequence is used, the SoC enters low power
mode before the ARM core executes WFI
No fix scheduled
10
eCSPI
ERR009606 eCSPI: In master mode, burst lengths of 32n + 1 will transmit incorrect data No fix scheduled
11
ERR009535 eCSPI: Burst completion by SS signal in slave mode is not functional No fix scheduled
12
EIM
ERR004446 EIM: AUS mode is nonfunctional for devices larger than 32 MB No fix scheduled
13
FlexCAN
ERR005829
FlexCAN: FlexCAN does not transmit a message that is enabled to be
transmitted in a specific moment during the arbitration process
No fix scheduled
14
I2C
ERR007805 I2C: When the I2C clock speed is configured for 400 kHz, the SCL low period
violates the I2C specification
No fix scheduled
16
MMC
ERR010450
MMC: EMMC can only run under or equal to 150 MHz No fix scheduled
17
MMDC
ERR005778
MMDC: DDR Controller’s measure unit may return an incorrect value when
operating below 100 MHz
No fix scheduled
18
ERR009596
MMDC: ARCR_GUARD bits of MMDC Core AXI Re-ordering Control register
(MMDC_MAARCR) does not behave as expected
No fix scheduled
19
PXP
ERR009541 PXP: PXP CSC2 cannot do RGB2YCbCr or RGB2YUV conversion correctly No fix scheduled
20
System Boot
ERR010449
System Boot: HAB HAL routine hab_hal_invalidate_cache should invalidate
L1/L2 D-cache, but did not in the ROM code
No fix scheduled
21
USB
ERR004535 USB: USB suspend and resume flow clarifications No fix scheduled
22
ERR006281 USB: Incorrect DP/DN state when only VBUS is applied No fix scheduled
23
ERR010661 USB: VBUS leakage occurs if USBOTG1 VBUS is on and USBOTG2 VBUS
transitions from on to off
No fix scheduled
24
Table 2. Summary of Silicon Errata (continued)
Errata Name
Solution
Page
