PCI 9054 and MPC860 Rapid Development Kit
Based on the powerful combination of the PLX PCI 9054 Bus Master I/O
Accelerator Chip and the Motorola MPC860 PowerQUICC micro-
processor, the PLX PCI 9054RDK-860 Rapid Development Kit (RDK)
provides a complete development environment for embedded
designs based on the Motorola MPC860 processor.
At the heart of the RDK is the PLX PCI 9054 Bus Master I/O
Accelerator which supports a 32-bit, 33MHz PCI Bus and 50 MHz
Local Bus. It provides a complete PCI v2.2 specification implementation
enabling burst transfers up to 132 Mbytes/second. The PCI 9054 incorporates
PLX’s industry leading advanced Data Pipe Architecture™ technology includ-
ing DMA engines, programmable PCI Initiator and Target data transfer modes
and PCI messaging functions.
The PCI 9054RDK-860 allows customers to quickly and easily add PCI to
a variety of applications in telecommunications and data communications
where the MPC860 excels.
The PLX PCI 9054RDK-860 Rapid Development Kit includes a PCI v2.2
compliant board and the PLX Software Development Kit Professional Edition
(SDK-PRO). The PCI SDK features a complete set of tools for software devel-
opment which significantly reduce the time necessary to develop PCI and I/O
Processor (IOP) based software. The PCI SDK includes PCI 9054 host and local
side application programming interface (API) object code libraries for the
Motorola MPC860. A Board Support Package (BSP) with “C” source code
provides everything necessary for porting to your target design. Also included
are sample Windows drivers with source code. Plus you also get PLXMon
®
, a
robust and comprehensive Windows based debug tool that allows for interac-
tive PCI and local bus monitoring, debugging, configuration, and code down-
load to the RDK board.
Features
■
PCI v2.2 compliant PCI
adapter board based on the
powerful PLX PCI 9054
Bus Master I/O Accelerator
chip with direct connect
to Motorola MPC860
PowerQUICC
■
50MHz Motorola MPC860
PowerQUICC processor
■
Complete OrCAD schematics
and hardware reference
manual
■
Sample PCI 9054 chip and
Data Book
SDK-PRO
■
Flexible PCI 9054 API object
code libraries for host and
MPC860
■
Board Support Package (BSP)
allows easy porting to your
design
■
Sample Windows NT device
drivers with source code
■
PLXMon, a comprehensive
debug tool for monitoring,
debugging, configuration and
code download
■
WxWorks ans pSOS BSP with
source code for quick RTOS
application development
■
Comprehensive reference
manuals for SDK and
PLXMon
Compatible Tools:
■
Compatible with software
development tools for the
Motorola MPC860
PCI 9054RDK-860
