Reason for Change
:
To improve productivity by qualifying MMT as an additional assembly site.
Change Implementation Status:
In Progress
Estimated Qualification Completion Date:
January 2018
Note: Please be advised the qualification completion times may be extended because of unforeseen
business conditions however implementation will not occur until after qualification has completed and a
final PCN has been issued. The final PCN will include the qualification report and estimated first ship
date. Also note that after the estimated first ship date guided in the final PCN customers may receive
pre and post change parts.
Time Table Summary:
November
2017
-->
January 2018
Workweek
44 45 46 47 48 01 02 03 04 05
Initial PCN
Issue Date
X
Qual Report
Availability
X
Final PCN
Issue Date
X
Method to Identify Change:
Traceability code
Qualification Plan:
Please open the attachments included with this PCN labeled as PCN_#_Qual Plan.
Revision History:
November 28, 2017: Issued initial notification.
The change described in this PCN does not alter Microchip’s current regulatory compliance regarding
the material content of the applicable products.
Attachment(s):
PCN_GBNG-08GYZA953_Affected CPN.pdf
PCN_GBNG-08GYZA953_Qual Plan.pdf
PCN_GBNG-08GYZA953_Affected CPN.xlsx
Please contact your local Microchip sales office with questions or concerns regarding this notification.
Terms and Conditions:
If you wish to change your product/process change notification (PCN) profile please log on to our website at http://www.microchip.com/PCN
sign into myMICROCHIP to open the myMICROCHIP home page, then select a profile option from the left navigation bar.
To opt out of future offer or information emails (other than product change notification emails), click here to go to microchipDIRECT and
login, then click on the "My account" link, click on "Update profile" and un-check the box that states "Future offers or information about
Microchip's products or services."
Page 2 of 3Product Change Notification - GBN
G
-08GYZA953 - 28 Nov 2017 - CCB 3181 Initial N
o
...
11
/
29
/
201
7
http://www.microchip.com/mymicrochip/NotificationDetails.aspx?pcn=GBN
G
-08GYZ
A
...
