PIC16(L)F1516/1517/1518/1519
DS80518E-page 2 2010-2012 Microchip Technology Inc.
TABLE 2: SILICON ISSUE SUMMARY
Module Feature
Item
Number
Issue Summary
Affected Revisions
(1)
A2 A3 A4 A6
High-Frequency Internal
Oscillator (HFINTOSC)
HFINTOSC Operation 1.1 HFINTOSC is not stable
when VDD <2.3V.
X
High-Frequency Internal
Oscillator (HFINTOSC)
HFINTOSC Operation 1.2 HFINTOSC Max. V
DD at
-40°C.
X
FVR FVR Ready Bit
(FVRRDY)
2.1 FVRRDY bit may not get
set at low VDD and low
operating temperature.
X
Oscillator HFINTOSC Ready/
Stable bit
3.1 Bits remained set to ‘1’
after initial trigger.
XXX
Oscillator Clock Switching 3.2 Clock switching can
cause a single corrupted
instruction.
XXX
Oscillator Oscillator Start-up
Timer (OST) bit
3.3 OST bit remains set. X X X
Configuration Word Configuration Word 1,
Bit 8
4.1 Writing the unimple-
mented Configuration
Word bit 8 affects bit 7.
XX
Low-Dropout (LDO) Volt-
age Regulator
Low-Power Sleep
mode
5.1 Unexpected Resets may
occur at ambient temper-
atures below 0
C.
XXXX
Note 1: Only those issues indicated in the last column apply to the current silicon revision.
