PIC16(L)F15354/55
DS40001853B-page 2 Preliminary 2016 Microchip Technology Inc.
Digital Peripherals (Cont.)
•I/O Pins:
- Individually programmable pull-ups
- Slew rate control
- Interrupt-on-change with edge-select
- Input level selection control (ST or TTL)
- Digital open-drain enable
• Peripheral Pin Select (PPS):
- Enables pin mapping of digital I/O
Analog Peripherals
• Analog-to-Digital Converter (ADC):
- 10-bit with up to 43 external channels
- Operates in Sleep
• Two Comparators:
- FVR, DAC and external input pin available on
inverting and noninverting input
- Software selectable hysteresis
- Outputs available internally to other modules,
or externally through PPS
• 5-Bit Digital-to-Analog Converter (DAC):
- 5-bit resolution, rail-to-rail
- Positive Reference Selection
- Unbuffered I/O pin output
- Internal connections to ADCs and
comparators
• Voltage Reference:
- Fixed Voltage Reference with 1.024V, 2.048V
and 4.096V output levels
• Zero-Cross Detect module
- AC high voltage zero-crossing detection for
simplifying TRIAC control
- Synchronized switching control and timing
Flexible Oscillator Structure
• High-Precision Internal Oscillator:
- Software selectable frequency range up to 32
MHz, ±1% typical
• x2/x4 PLL with Internal and External Sources
• Low-Power Internal 32 kHz Oscillator
(LFINTOSC)
• External 32 kHz Crystal Oscillator (SOSC)
• External Oscillator Block with:
- Three crystal/resonator modes up to 20 MHz
- Three external clock modes up to 32 MHz
• Fail-Safe Clock Monitor:
- Allows for safe shutdown if primary clock
stops
• Oscillator Start-up Timer (OST):
- Ensures stability of crystal oscillator
resources
