2015 Microchip Technology Inc. DS80000676A-page 1
PIC16(L)F1777/8/9
The PIC16(L)F1777/8/9 family devices that you have
received conform functionally to the current Device
Data Sheet (DS40001819A), except for the anomalies
described in this document.
The silicon issues discussed in the following pages are
for silicon revisions with the Device and Revision IDs
listed in Table 1. The silicon issues are summarized in
Table 2.
The errata described in this document will be addressed
in future revisions of the PIC16(L)F1777/8/9 silicon.
Data Sheet clarifications and corrections start on page
5, following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
IDE and Microchip’s
programmers, debuggers, and emulation tools, which
are available at the Microchip corporate website
(www.microchip.com).
For example, to identify the silicon revision level
using MPLAB IDE in conjunction with a hardware
debugger:
1. Using the appropriate interface, connect the
device to the hardware debugger.
2. Open an MPLAB IDE project.
3. Configure the MPLAB IDE project for the
appropriate device and hardware debugger.
4. Based on the version of MPLAB IDE you are
using, do one of the following:
a) For MPLAB IDE 8, select Programmer >
Reconnect.
b) For MPLAB X IDE, select Window >
Dashboard and click the Refresh Debug
Tool Status icon ( ).
5. Depending on the development tool used, the
part number and Device Revision ID value
appear in the Output window.
The DEVREV values for the various PIC16(L)F1777/8/
9 silicon revisions are shown in Table 1.
Note: This document summarizes all silicon
errata issues from all revisions of silicon,
previous as well as current. Only the
issues indicated in the last column of
Table 2 apply to the current silicon
revision (A0).
Note: If you are unable to extract the silicon
revision level, please contact your local
Microchip sales office for assistance.
TABLE 1: SILICON DEVREV VALUES
Part Number Device ID
(1)
Revision ID Silicon Revision
(2)
A0
PIC16F1777 308Eh 2000h
PIC16LF1777 3091h 2000h
PIC16F1778 308Fh 2000h
PIC16LF1778 3092h 2000h
PIC16F1779 3090h 2000h
PIC16LF1779 3093h 2000h
Note 1: The Device ID is located in the configuration memory at address 8006h.
2: Refer to the “PIC16(L)F177X Memory Programming Specification” (DS40001792) for detailed information
on Device and Revision IDs for your specific device.
PIC16(L)F1777/8/9 Family
Silicon Errata and Data Sheet Clarification
