2
8-bit PIC® Microcontroller Solutions
The Industry’s Broadest MCU Offering
There are over 800 8-bit PIC microcontrollers ranging from
6 to 100 pins and up to 128 KB Flash that are pin and
code compatible across the portfolio. PIC microcontrollers
with XLP technology feature the world’s lowest active
and sleep power consumption with flexible power modes
and wake-up sources. MPLAB® X Integrated Development
Environment (IDE) supports all PIC microcontrollers with XC
Compiler support and common development boards.
Peripherals, Performance, and Price Points
for any Application
Peripheral integration is key with communication and
control peripherals like SPI, I
2
C™, UART, PWM, ADC,
DAC, op amps, as well as specialized peripherals for
USB, LCD and Ethernet. In addition, Microchip offers the
Core Independent Peripherals that provide even higher
levels of flexibility and integration which has never been
possible in the 8-bit microcontrollers. These new Core
Independent Peripherals include Configurable Logic
Cell (CLC), Complementary Output Generator (COG),
Numerically Controlled Oscillator (NCO), Zero Cross
Detect (ZCD) and Hardware CVD (Capacitive Voltage
Divider). Customers have made PIC MCUs a worldwide
standard, with over one million development systems
shipped. PIC microcontrollers are quick and easy to
design into a wide variety of applications with a long
history of dependable product delivery.
Scalability & Migration
To provide customers a low-risk development environment,
PIC microcontrollers offer seamless migration within the
complete range of products. The 8-bit PIC microcontroller
family is pin-compatible within a given pin count as well as
code compatible between the architectures. Being able to
migrate easily between various PIC MCUs allows flexibility
to react to changing design requirements and feature
enhancements. Maximize re-use for future developments
and preserve the investment in hardware, software and
tools by choosing Microchip.
Strength Through Design
In an effort to meet the needs of embedded
system designers, silicon manufacturers continue
to increase functionality and performance while
decreasing the physical size and cost. This provides
a significant benefit to both the embedded system
designer and end consumer, but as the demand for
sophisticated consumer and embedded products
continues to expand, so does the challenge of
properly designing such applications.
As semiconductor technology continues to evolve
into “smaller, faster and cheaper”, so does the
challenge to provide key features and attributes
necessary for embedded design. Microchip is
committed to implementing technology advances that
not only increase performance and reduce cost of
the microcontroller, but do so without sacrificing key
features such as:
■ 5V: As an 8-bit leader, we understand the need for
5V devices and will continue to support it.
■ EEPROM: A key requirement for many embedded
designs, cost effective implementation is critical.
■ Analog Integration: Having a rich Analog offering
available in a low cost MCU is a must have for
many of today’s embedded challenges.
■ High Voltage Variants: Allows for connection to an
application that has high voltage rails, without the
need of an external regulator.
■ EMC: Designed to minimize susceptibility to
EMI/EMC, providing the most electrically durable
solutions in the industry.
Overview
Get Ready to See a New World of 8-bit PIC® Microcontrollers
PIC microcontrollers are finding their way into new applications like solar battery chargers, advanced medical devices and
solid state lighting. Microchip provides solutions for the entire performance range of 8-bit microcontrollers, with easy-to-
use development tools, complete technical documentation, design-in and production support through a global sales and
distribution network.
