R5F100FFAFP#V0 其他数据使用手册 - Renesas Electronics（瑞萨电子）

制造商:

Renesas Electronics（瑞萨电子）

分类:

微控制器

封装:

LQFP-44

描述:

RL78/G13，16 位微控制器，数据闪存安装，Renesas ElectronicsRL78 是 Renesas Electronics 下一代微控制器系列，结合了 78K 和 R8C 系列的高级功能，以实现低功耗 (66uA/MHz) 和高性能 (41DMIPS @ 32MHz)。 RL78 基于具有丰富模拟功能的 16 位 CISC 体系结构。平台系列产品将包括通用设备、LCD 和 ASSP，其中包括照明和汽车微控制器。 RL78 专门为超低功率应用而设计，使客户能够以低成本构建紧凑型和高能效系统。除了高精度 (±1%) 芯片振荡器促成 32MHz CPU 操作，以及 RL78/G13 的其他标准芯片功能，RL78/G14 微控制器拥有乘、除和倍乘积累指令，比 RL78/G13 的处理速度更快，并且 R8C 系列的功能，具有经验证的记录，例如计时器 RD/RG/RJ、数据传输控制器，以及事件链接控制器，有助于降低建立一个系统的总成本，尺寸更加紧凑，功率消耗更低。### 注安装数据闪存。### RL78 系列微控制器，Renesas Electronics

Pictures:

3D模型

符号图

焊盘图

引脚图

产品图

页面导航:

引脚图在P16Hot

原理图在P34

封装尺寸在P176P177P178P179P180P181P182P183P184P185P186P187

型号编码规则在P4P5P6P7P8P9P10P11P12P13P14P15

封装信息在P3

技术参数、封装参数在P54P55P56P57P58P59P60P61P62P63P64P65

应用领域在P1

电气规格在P54P55P56P57P58P59P60P61P62P63P64P65

型号编号列表在P3P4P5P6P7P8P9P10P11P12P13P14

导航目录

引脚图在P16
原理图在P34
封装尺寸在P176 P177 P178 P179 P180 P181 P182 P183 P184 P185 P186 P187
型号编码规则在P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15
封装信息在P3
技术参数、封装参数在P54 P55 P56 P57 P58 P59 P60 P61 P62 P63 P64 P65
应用领域在P1
电气规格在P54 P55 P56 P57 P58 P59 P60 P61 P62 P63 P64 P65
型号编号列表在P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14

R5F100FFAFP#V0数据手册

Page:

of 200 Go

PDF下载

若手册格式错乱，请下载阅览PDF原文件

Datasheet

RL78/G13

RENESAS MCU

True Low Power Platform (as low as 66 µA/MHz, and 0.57 µA for RTC + LVD), 1.6 V to 5.5 V

operation, 16 to 512 Kbyte Flash, 41 DMIPS at 32 MHz, for General Purpose Applications

Page 1 of 194

R01DS0131EJ0310

Rev.3.10

Nov 15, 2013

R01DS0131EJ0310 Rev.3.10

Nov 15, 2013

1. OUTLINE

1.1 Features

Ultra-Low Power Technology

• 1.6 V to 5.5 V operation from a single supply

• Stop (RAM retained): 0.23 µA, (LVD enabled): 0.31

µA

• Halt (RTC + LVD): 0.57 µA

• Snooze: 0.70 mA (UART), 1.20 mA (ADC)

• Operating: 66 µA/MHz

16-bit RL78 CPU Core

• Delivers 41 DMIPS at maximum operating frequency

of 32 MHz

• Instruction Execution: 86% of instructions can be

executed in 1 to 2 clock cycles

• CISC Architecture (Harvard) with 3-stage pipeline

• Multiply Signed & Unsigned: 16 x 16 to 32-bit result in

1 clock cycle

• MAC: 16 x 16 to 32-bit result in 2 clock cycles

• 16-bit barrel shifter for shift & rotate in 1 clock cycle

• 1-wire on-chip debug function

Main Flash Memory

• Density: 16 KB to 512 KB

• Block size: 1 KB

• On-chip single voltage flash memory with protection

from block erase/writing

• Self-programming with secure boot swap function

and flash shield window function

Data Flash Memory

• Data Flash with background operation

• Data flash size: 4 KB to 8 KB size options

• Erase Cycles: 1 Million (typ.)

• Erase/programming voltage: 1.8 V to 5.5 V

RAM

• 2 KB to 32 KB size options

• Supports operands or instructions

• Back-up retention in all modes

High-speed On-chip Oscillator

• 32 MHz with +/− 1% accuracy over voltage (1.8 V to

5.5 V) and temperature (−20 °C to 85 °C)

• Pre-configured settings: 32 MHz, 24 MHz, 16 MHz,

12 MHz, 8 MHz, 6 MHz, 4 MHz, 3 MHz, 2 MHz,

and 1 MHz

Reset and Supply Management

• Power-on reset (POR) monitor/generator

• Low voltage detection (LVD) with 14 setting options

(Interrupt and/or reset function)

Data Memory Access (DMA) Controller

• Up to 4 fully programmable channels

• Transfer unit: 8- or 16-bit

Multiple Communication Interfaces

• Up to 8 x I

C master

• Up to 2 x I

C multi-master

• Up to 8 x CSI/SPI (7-, 8-bit)

• Up to 4 x UART (7-, 8-, 9-bit)

• Up to 1 x LIN

Extended-Function Timers

• Multi-function 16-bit timers: Up to 16 channels

• Real-time clock (RTC): 1 channel (full calendar and

alarm function with watch correction function)

• Interval Timer: 12-bit, 1 channel

• 15 kHz watchdog timer : 1 channel (window function)

Rich Analog

• ADC: Up to 26 channels, 10-bit resolution, 2.1 µs

conversion time

• Supports 1.6 V

• Internal voltage reference (1.45 V)

• On-chip temperature sensor

Safety Features (IEC or UL 60730 compliance)

• Flash memory CRC calculation

• RAM parity error check

• RAM write protection

• SFR write protection

• Illegal memory access detection

• Clock stop/ frequency detection

• ADC self-test

General Purpose I/O

• 5V tolerant, high-current (up to 20 mA per pin)

• Open-Drain, Internal Pull-up support

• Different potential interface support: Can connect to

a 1.8/2.5/3 V device

Operating Ambient Temperature

• Standard: −40 °C to +85 °C

• Extended: −40 °C to +105 °C

Package Type and Pin Count

From 3mm x 3mm to 14mm x 20mm

QFP: 44, 48, 52, 64, 80, 100, 128

QFN: 24, 32, 40, 48

SSOP: 20, 30

LGA: 25, 36

BGA: 64

1
2
3
4
5
•••
200
