76 Ohmite Mfg. Co. 1600 Golf Rd., Suite 850, Rolling Meadows, IL 60008 • Tel. 1-866-9-OHMITE • Fax 1-847-574-7522 • www.ohmite.com • info@ohmite.com
Rheostat and
Tap Switch Hardware
Knobs, Dials, Mounting Fasteners
EXTRA MOUNTING HARDWARE
Kit contains 25 each, nuts and lock washers for panel mounting
units.
Part No. For model
✔ 7090 E
✔ 7091 H, J, G, K, L, 111, 212, 711
RHEOSTAT TANDEM COUPLING KITS
Part No. Front mount models Rear mount models Max. panel thickness
✙ 6532 H, J H, J, G, K, L
5
/
32"
✔ 6533 G, K, L H, J, G, K, L
1
/
8"
✜ 6591 E E
1
/
16"
Ohmite coupling kits permit tandem mounting of two rheostat
units. A coupling fastens to the shaft of the back unit; projections
on the coupling engage the recesses in the driving hub of the
front unit.
Each kit consists of a steel “U” frame, a coupling with set
screw, mica washer, allen wrench and instructions.
RHEOSTAT REPAIR KITS
Part No. Rheostat model
✔ 7070 P
✔ 7071 N
✔ 7072 R
✔ 7074 U
Designed for replacing electrical contact.
Kit includes contact/slip ring assemblies
(for round and ribbon wire rheostats),
copper graphite washer, spring arm and
hub. Instructions included.
✙ = Most popular stock values
✔ = Stock values
✜ = Non-stock values subject to minimum handling charge per item
Any knob can be used with any rheostat and tap switch model
which has the corresponding shaft diameter. Knobs are fastened
to shafts with slotted set screws.
Slotted Hex socket Knob Hole
set screw set socket Description dia. dia.
✜ 5102 — Bar knob, 2
1
/4" long —
1
/4"
✙ 5103 ✔ 5103A Bar knob, 1
1
/4" long —
1
/4"
✙ 5104 ✔ 5104A Handwheel with pointer 3
1
/4"
3
/8"
✔ 5105
1
— Handwheel without pointer 3
1
/4"
3
/8"
✔ 5106 ✜ 5106A Handwheel with pointer 3
1
/4"
1
/4"
✜ 5107 — Handwheel without pointer 3
1
/4"
1
/4"
✙ 5109 ✔ 5109A Finger-grip with pointer 1
5
/8"
1
/4"
✙ 5110 ✜ 5110A Finger-grip without pointer 1
5
/8"
1
/4"
✔ 5111 ✙ 5111A Finger-grip with pointer 2
3
/8"
1
/4"
✜ 5112 ✜ 5112A Finger-grip without pointer 2
3
/8"
1
/4"
✜ 5115
2
— Bar knob, 4
3
/
4"—
3
/
8"
✙ 5116 ✜ 5116A Bar knob, 1
1
/
2"—
1
/
4"
✙ 5150
3
✜ 5150A Finger-grip 1
1
/
2"
1
/
4"
✙ 5151
4
— Finger-grip
3
/
4"
1
/
8"
— ✔ 5152A Like 5104 (shorter pointer) 3
1
/
4"
1
/
4"
1
Recommended for rheostat models P, N, R,, U.
2
Requires pin and tapped hole in shaft.
3
Recommended for rheostat models H, J, G, K, L.
4
Recommended for rheostat models C, E.
DIALS
Handsomely finished, black-enameled, aluminum dials for
Ohmite rheostats and tap switches. Figures and lines are etched
on a black background for contrast and ease of readability. On
rheostat dials, divisions indicating approximate percentage of
rheostat resistance in circuit are marked from 0 to 100. On tap
switch dials, Number of dial positions are identical with number
of switch positions.
Part No. For model For knob Dial dia.
✙ 5007 C, E 5151 1
1
/4"
✙ 5000 H, J, G, K, L 5150, 5116, 5103 2
3
/16"
✔ 5001 P, N, R, U 5104, 5106 5
1
/2"
✔ 5002-* 111, 212 (single), 312 (single) 5109, 5116, 5150 2
3
/4"
✔ 5003-* 212 (tandem), 312 (tandem), 412 5111, 5152A 3
3
/4"
✔ 5004-* 608 5104, 5115 5
1
/2"
*Specify number of positions as suffix.
KNOBS
Finger grip
with pointer
Finger grip
without pointer
Handwheel
with pointer
Handwheel
without pointer
Finger grip Bar knob,
1.5" long
Bar knob,
4.75" long
For
rheostats
For tap
switches
