SBL3040C DIODE
UNISONIC TECHNOLOGIES CO., LTD 2 of 3
www.unisonic.com.tw QW-R601-018.C
ABSOLUTE MAXIMUM RATINGS (T
A
=25°C, unless otherwise specified)
PARAMETER SYMBOL RATINGS UNIT
Recurrent Peak Reverse Voltage V
RRM
40 V
RMS Voltage V
R
WM
40 V
DC Blocking Voltage V
R
40 V
Average Forward Rectified Current
Per Leg
I
F(AV)
15
A
Per Package 30
Peak Forward Surge Current 8.3ms Single Half
Sine-Wave Superimposed on Rated Load Per Diode
I
FSM
250 A
Operating Junction Temperature T
J
150 °C
Storage Temperature T
STG
-55~+150 °C
Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2. Thermal resistance junction to case mounted on heatsink.
THERMAL CHARACTERISTICS (T
A
=25°C, unless otherwise noted.)
PARAMETER SYMBOL RATINGS UNIT
Junction to Case θ
JC
1.5 °C/W
ELECTRICAL CHARACTERISTICS (T
A
=25°C, unless otherwise noted.)
PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT
Instantaneous Forward Voltage (Note 1) V
F
T
C
=25°C, I
F
=15A 0.55 V
Total Capacitance (Note 2) C
T
450 pF
Instantaneous Reverse Current at Rated DC
Blocking Voltage Per Diode
(Note 1)
I
R
T
C
=25°C 1.0 mA
T
C
=100°C 75 mA
Notes: 1. Pulse Test: 300μs pulse width, 1% duty cycle.
2. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
