Si5347/46/45/44/42/41/40 Errata (A1) Silicon Labs Confidential Page 1
12-August-2014
Si5347/46, Si5345/44/42, Si5341/40
Silicon Revision A1 Errata
Errata Status Summary
Errata #
Title
Impact
Status
1
Output frequency limited to 710 MHz.
Major
May be fixed in a future revision.
2
OSC startup issue w/ XTALs if Tj > 110 °C.
Major
Fixed in silicon revision B.
3
Input-to-Output delay is not consistent.
Major
No workaround.
Will be fixed in a future revision.
4
Output-to-Output skew is not consistent.
Major
No workaround.
Will be fixed in a future revision.
5
LVCMOS Hi-Z mode impedance too low.
Major
No workaround.
Will be fixed in a future revision.
6
LOS and OOF sticky status bits cannot be cleared.
Minor
No workaround.
Will be fixed in a future revision.
Impact definition: Each erratum is marked with an impact, as defined below:
Minor – Workaround exists.
Major – Errata that do not conform to the data sheet or standard.
Information – The device behavior is not ideal but acceptable. Typically, the data sheet
will be changed to match the device behavior.
This document applies to Ordering Part Numbers (OPNs) which refer to product
Revision A (silicon revision A1). For example: Si5345A-A-GM or Si5341A-Axxxxx-GM,
where xxxxx is the custom OPN ID.
Silicon revision B will have OPNs with B in the product revision. For example: Si5345A-
B-GM or Si5341A-Bxxxxx-GM, where xxxxx is the custom OPN ID.
