STB11N65M5, STD11N65M5, STF11N65M5,
STP11N65M5, STU11N65M5
N-channel 650 V, 0.43 Ω typ., 9 A MDmesh™ V Power MOSFET
in D
2
PAK, DPAK, TO-220FP, TO-220 and IPAK packages
Datasheet — production data
Features
■ Worldwide best R
DS(on)
* area
■ Higher V
DSS
rating and high dv/dt capability
■ Excellent switching performance
■ 100% avalanche tested
Applications
■ Switching applications
Description
These devices are N-channel MDmesh™ V
Power MOSFETs based on an innovative
proprietary vertical process technology, which is
combined with STMicroelectronics’ well-known
PowerMESH™ horizontal layout structure. The
resulting product has extremely low on-
resistance, which is unmatched among silicon-
based Power MOSFETs, making it especially
suitable for applications which require superior
power density and outstanding efficiency.
Figure 1. Internal schematic diagram
Order codes
V
DSS
@
T
Jmax
R
DS(on)
max
I
D
STB11N65M5
710 V < 0.48 Ω 9 A
STD11N65M5
STF11N65M5
STP11N65M5
STU11N65M5
D
2
PAK
TO-220
TO-220FP
DPAK
1
3
2
TAB
1
2
3
1
2
3
TAB
1
3
TAB
2
3
2
1
IPAK
!-V
$4!"
'
3
Table 1. Device summary
Order codes Marking Package Packaging
STB11N65M5
11N65M5
D
2
PA K
Tape and reel
STD11N65M5 DPAK
STF11N65M5 TO-220FP
TubeSTP11N65M5 TO-220
STU11N65M5 IPAK
