STM32F030K6T6数据手册
Page:
of 91 Go
若手册格式错乱，请下载阅览PDF原文件
This is information on a product in full production.
January 2017 DocID024849 Rev 3 1/91
STM32F030x4 STM32F030x6
STM32F030x8 STM32F030xC
Value-line ARM
®
-based 32-bit MCU with up to 256 KB Flash,
timers, ADC, communication interfaces, 2.4-3.6 V operation
Datasheet - production data
Features
• Core: ARM
®
32-bit Cortex
®
-M0 CPU,
frequency up to 48 MHz
• Memories
– 16 to 256 Kbytes of Flash memory
– 4 to 32 Kbytes of SRAM with HW parity
• CRC calculation unit
• Reset and power management
– Digital & I/Os supply: V
DD
= 2.4 V to 3.6 V
– Analog supply: V
DDA
= V
DD
to 3.6 V
– Power-on/Power down reset (POR/PDR)
– Low power modes: Sleep, Stop, Standby
• Clock management
– 4 to 32 MHz crystal oscillator
– 32 kHz oscillator for RTC with calibration
– Internal 8 MHz RC with x6 PLL option
– Internal 40 kHz RC oscillator
• Up to 55 fast I/Os
– All mappable on external interrupt vectors
– Up to 55 I/Os with 5V tolerant capability
• 5-channel DMA controller
• One 12-bit, 1.0 µs ADC (up to 16 channels)
– Conversion range: 0 to 3.6 V
– Separate analog supply: 2.4 V to 3.6 V
• Calendar RTC with alarm and periodic wakeup
from Stop/Standby
• 11 timers
– One 16-bit advanced-control timer for
six-channel PWM output
– Up to seven 16-bit timers, with up to four
IC/OC, OCN, usable for IR control
decoding
– Independent and system watchdog timers
– SysTick timer
• Communication interfaces
– Up to two I
2
C interfaces
– Fast Mode Plus (1 Mbit/s) support on
one or two I/Fs, with 20 mA current sink
– SMBus/PMBus support (on single I/F)
– Up to six USARTs supporting master
synchronous SPI and modem control; one
with auto baud rate detection
– Up to two SPIs (18 Mbit/s) with 4 to 16
programmable bit frames
• Serial wire debug (SWD)
• All packages ECOPACK
®
2
Table 1. Device summary
Reference Part number
STM32F030x4 STM32F030F4
STM32F030x6 STM32F030C6, STM32F030K6
STM32F030x8 STM32F030C8, STM32F030R8
STM32F030xC STM32F030CC, STM32F030RC
LQFP64 (10x10 mm)
LQFP48 (7x7 mm)
LQFP32 (7x7 mm)
TSSOP20 (6.4x4.4 mm)
www.st.com
