STM32F030K6T6 产品描述及参数 - ST Microelectronics（意法半导体）
制造商:
ST Microelectronics（意法半导体）
分类:
微控制器
封装:
LQFP-32
描述:
STMICROELECTRONICS STM32F030K6T6 微控制器, 32位, Value Line价值线, ARM 皮质-M0, 48 MHz, 32 KB, 4 KB, 32 引脚, LQFP
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
STM32F030K6T6数据手册
Page:
of 3 Go
若手册格式错乱，请下载阅览PDF原文件
For further information contact your local STMicroelectronics sales office.
September 2014 DocID025096 Rev 2 1/3
32F0308DISCOVERY
Discovery kit for STM32F030 Value Line
Data brief
Features
• STM32F030R8T6 microcontroller featuring
64 KB of Flash memory, 8 KB of RAM in an
LQFP64 package
• On-board ST-LINK/V2 with selection mode
switch to use the kit as a standalone
ST-LINK/V2 (with SWD connector for
programming and debugging)
• Board power supply: through USB bus or from
an external 5 V supply voltage
• External application power supply: 3 V and 5 V
• Four LEDs:
– LD1 (red) for 3.3 V power-on
– LD2 (red/green) for USB communication
– LD3 (green) for PC9 output
– LD4 (blue) for PC8 output
• Two push-buttons (user and reset)
• Extension header for all LQFP64 I/Os for quick
connection to prototyping board and easy
probing
• An additional board is provided which can be
connected to the extension connector for even
easier prototyping and probing
• Comprehensive free software including a
variety of examples, part of STM32CubeF0
package or STSW-STM32140 for legacy
Standard Libraries usage
Description
The 32F0308DISCOVERY helps you to discover
the STM32 F030 Value Line Cortex
®
-M0 features
and to develop your applications easily. It includes
everything required for beginners and
experienced users to get started quickly.
Based on the STM32F030R8T6, an STM32 F0
series 32-bit ARM
®
Cortex
®
microcontroller, it
includes an ST-LINK/V2 embedded debug tool,
LEDs, push-buttons and a prototyping board for
easy connection of additional components and
modules.
www.st.com
