STM32F100VBT6B 其他数据使用手册 - ST Microelectronics（意法半导体）
制造商:
ST Microelectronics（意法半导体）
分类:
微控制器
封装:
LQFP-100
描述:
STM32F100 超值系列微处理器，STMicroelectronicsSTM32F100 超值型基于 ARM Cortex™ M3 MCU，包含带电动机控制和 CEC 功能的 24 MHz CPU。 STM32 系列 ARM Cortex-M3 32 位闪存微控制器产品系列在低功率、低电压情况下运行，结合了带有实时功能的高性能。 它们为引脚到引脚接线并兼容软件。 STMicroelectronics 高级 ARM 32 位处理器低密度和中密度超值型带高达 512 KB 的闪存、计时器、ADC、DAC 和通信接口，还提供不同的封装。 ST 的 STM32F100 微控制器系列适用于多种区域，例如应用控制和用户接口；医疗和手持设备；PC 和游戏外设；GPS 平台和工业应用。 32 位 RISC；高达 512 KB 闪存；高达 32 KB SRAM 温度范围：- 40 至 +85 °C 低电压：2 V 至 3.6 V ### STM32F1 系列 32 位 ARM® Cortex®-M3 微控制器，STMicroelectronics32 位闪存微控制器的 STM32 系列基于 ARM Cortex™ M3 核心的突破 - 为嵌入式应用特别开发的核心。 STM32 系列得益于 Cortex-M3 体系结构增强功能，包括为传达改进性能而设置的 Thumb-2 指令，带更好的编码密度，对中断更快的反应，所有的均和领先的工业功耗相接合。出色的实时表现 卓越功效 卓越的和新型的外围设备 最大程度的集成 跨族引脚，外围设备和软件兼容性展开
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
引脚图在P22P23P24P25P26P27P28P29Hot
典型应用电路图在P48P50P71
封装尺寸在P76P77P78P79P80P81P82P83P84P85P86P87
型号编码规则在P90P91P92
技术参数、封装参数在P33P55
电气规格在P31P32P33P34P35P36P37P38P39P40P41P42
导航目录
STM32F100VBT6B数据手册
Page:
of 97 Go
若手册格式错乱，请下载阅览PDF原文件
This is information on a product in full production.
November 2016 DocID16455 Rev 9 1/96
STM32F100x4 STM32F100x6
STM32F100x8 STM32F100xB
Low & medium-density value line, advanced ARM
®
-based 32-bit MCU
with 16 to 128 KB Flash, 12 timers, ADC, DAC & 8 comm interfaces
Datasheet - production data
Features
• Core: ARM
®
32-bit Cortex
®
-M3
CPU
– 24 MHz maximum frequency,
1.25 DMIPS/MHz (Dhrystone 2.1)
performance
– Single-cycle multiplication and hardware
division
• Memories
– 16 to 128 Kbytes of Flash memory
– 4 to 8 Kbytes of SRAM
• Clock, reset and supply management
– 2.0 to 3.6 V application supply and I/Os
– POR, PDR and programmable voltage
detector (PVD)
– 4-to-24 MHz crystal oscillator
– Internal 8 MHz factory-trimmed RC
– Internal 40 kHz RC
– PLL for CPU clock
– 32 kHz oscillator for RTC with calibration
• Low power
– Sleep, Stop and Standby modes
–V
BAT
supply for RTC and backup registers
• Debug mode
– Serial wire debug (SWD) and JTAG
interfaces
• DMA
– 7-channel DMA controller
– Peripherals supported: timers, ADC, SPIs,
I
2
Cs, USARTs and DACs
• 1 × 12-bit, 1.2 µs A/D converter (up to 16
channels)
– Conversion range: 0 to 3.6 V
– Temperature sensor
• 2 × 12-bit D/A converters
• Up to 80 fast I/O ports
– 37/51/80 I/Os, all mappable on 16 external
interrupt vectors and almost all 5 V-tolerant
• Up to 12 timers
– Up to three 16-bit timers, each with up to 4
IC/OC/PWM or pulse counter
– 16-bit, 6-channel advanced-control timer:
up to 6 channels for PWM output, dead
time generation and emergency stop
– One 16-bit timer, with 2 IC/OC, 1
OCN/PWM, dead-time generation and
emergency stop
– Two 16-bit timers, each with
IC/OC/OCN/PWM, dead-time generation
and emergency stop
– 2 watchdog timers (Independent and
Window)
– SysTick timer: 24-bit downcounter
– Two 16-bit basic timers to drive the DAC
• Up to 8 communications interfaces
– Up to two I
2
C interfaces (SMBus/PMBus)
– Up to 3 USARTs (ISO 7816 interface, LIN,
IrDA capability, modem control)
– Up to 2 SPIs (12 Mbit/s)
– Consumer electronics control (CEC)
interface
• CRC calculation unit, 96-bit unique ID
• ECOPACK
®
packages
Table 1. Device summary
Reference Part number
STM32F100x4 STM32F100C4, STM32F100R4
STM32F100x6 STM32F100C6, STM32F100R6
STM32F100x8
STM32F100C8, STM32F100R8,
STM32F100V8
STM32F100xB
STM32F100CB, STM32F100RB,
STM32F100VB
)%*$
LQFP100 14 × 14 mm
LQFP64 10 × 10 mm
LQFP48 7 × 7 mm
TFBGA64 5 × 5 mm
www.st.com
