DocID029276 Rev 1 3/9
TN1235 Overview of features
9
2 Overview of features
For a given board (Nucleo, discovery and evaluation boards), the user manual is the
reference document to know which version of the ST-LINK is embedded in the board.
Below is the overview of the features supported by each of the ST-LINK versions.
2.1 The ST-LINK key features
Here are the key features of the ST-LINK:
• 5V power supplied by USB connector.
• USB 2.0 full speed interface compatible.
• USB standard A to Mini-B cable provided.
• SWIM specific features: 1.65 V to 5.5 V application voltage supported on SWIM
interface.
• SWIM Low-speed and High-speed modes supported.
• SWIM programming speed rates of 9.7 K bytes/s in Low-speed, 12.8 Kbytes/s in High-
speed.
• SWIM cable for connection to an application with an ERNI standard connector vertical
(ref: 284697 or 214017) or horizontal (ref: 214012).
• SWIM cable for connection to an application with pin headers or 2.54 mm pitch
connector.
• JTAG/SWD specific features: 3 V to 3.6 V application voltage supported on JTAG/SWD
interface and 5 V tolerant inputs.
• JTAG/SWD cable provided for connection to a standard JTAG 20-pin pitch 2.54 mm
connector.
• Direct firmware update feature supported.
• Status LED which blinks during communication with PC.
• Operating temperature 0 to 50 °C.
2.2 The ST-LINK/V2 key features
Here are the key features of the ST-LINK/V2:
• 5V power supplied by a USB connector.
• USB 2.0 full-speed-compatible interface.
• USB standard A to Mini- B cable.
• SWIM specific features 1.65 V to 5.5 V application voltage supported on SWIM
interface.
• SWIM low-speed and high-speed modes supported.
• SWIM programming speed rate: 9.7 Kbytes/s in Low-speed and 12.8 Kbytes/s in High-
speed.
• SWIM cable for connection to the application via an ERNI standard vertical connector
(ref: 284697 or 214017) or horizontal connector (ref: 214012).
